Manufacturer: Allen-Bradley (Rockwell Automation)
Series: PowerFlex 753
Catalog Number: 20F1AND186AA0NNNNN
ALLEN-BRADLEY PowerFlex Air Cooled 753 AC Drive
| Parameter | Specification | Notes / Source Verification |
| Product Identification | ||
| Product Type | AC Drive / Variable Frequency Drive (VFD) | PowerFlex 753 series |
| Part Number | 20F1AND186AA0NNNNN | Unique identifier for this configuration |
| UPC | 884951167902 | Universal Product Code |
| Electrical Ratings | ||
| Input Voltage | 380-480V AC (3-Phase) | 480V nominal / 432-528V range |
| Output Current | 186 Amps | Continuous rated output current |
| Horsepower (Normal Duty) | 150 HP (110 kW) | Standard overload capacity |
| Horsepower (Heavy Duty) | 125 HP (90 kW) | High overload capacity |
| DC Bus Voltage | Approx. 650 V DC | Internal bus voltage level |
| Output Frequency | 0-400 Hz | Operating frequency range |
| Input Phases | 3 | Three-phase input only |
| Hardware Configuration | ||
| Enclosure Rating | IP20 / IP00 (Open Type) | Suitable for enclosure mounting; not standalone rated |
| Frame Size | Frame 6 | Mechanical frame designation |
| Braking | Internal Dynamic Braking Transistor | Allows use of external resistor |
| Filtering | Filtered (CM Jumper Removed) | EMC filtering configuration |
| Cooling Method | Air Cooled | Forced convection cooling |
| Input Configuration | AC Input with Precharge | Standard AC line input |
| Physical & Environmental | ||
| Weight | Approx. 49.9 kg (110 lbs) | Shipping weight |
| Dimensions (HxWxD) | 665.5 x 308 x 346.4 mm | Approximate dimensions (26.2″ x 12.1″ x 13.6″) |
| Features & Interface | ||
| Human Interface Module (HIM) | None (Blank Plate) | “AA” in part number indicates no HIM |
| Local I/O | Built-in | Basic discrete I/O included on board |
| Expansion Slots | 3 Slots Available | For communication or I/O expansion |
| Control Method | V/Hz, Vector Control | Standard for 753 series |
| Safety Features | Safe Torque Off (STO) | Integrated safety function |
