7MB2335-0NW06-3AA1
Ultramat 23 gas analyzer for 1 Component and oxygen measurement (option) Ultramat 23 gas analyzer for 1 Component and oxygen measurement (option) 19″ plug-in unit for mounting in enclosurrs, gas connections 6 mm stub, without internal sample gas pump. 19″ plug-in unit for mounting in enclosurrs, gas connections 6 mm stub, without internal sample gas pump. Component to be measured: SO2 Component to be measured: SO2 Min. measuring range: 0 to 400 mg/m3 Max. measuring range: 0 to 2000 mg/m3 Min. measuring range: 0 to 400 mg/m3 Max. measuring range: 0 to 2000 mg/m3 without O2-Sensor without O2-Sensor Without H2S-Sensor Without H2S-Sensor Power supply: AC 230 V, 50 Hz Power supply: AC 230 V, 50 Hz . . . . Operator’s software and documentation in english Operator’s software and documentation in english
| Order Number | 7MB2335-0NW06-3AA1 |
| Product Family | ULTRAMAT 23 |
| Product Type | Gas Analyzer |
| Measurement Capability | 1 component + oxygen measurement (option) |
| Mounting Type | 19″ plug‑in unit for mounting in enclosures |
| Gas Connections | 6 mm stub |
| Internal Sample Gas Pump | Without internal sample gas pump |
| Component Measured | SO₂ (sulfur dioxide) |
| SO₂ – Min. Measuring Range | 0 to 400 mg/m³ |
| SO₂ – Max. Measuring Range | 0 to 2000 mg/m³ |
| O₂ Sensor | Without O₂ sensor |
| H₂S Sensor | Without H₂S sensor |
| Power Supply | AC 230 V, 50 Hz |
| Operator Software / Documentation | Operator’s software and documentation in English |
| Net Weight | 12.000 kg |
| Packaging Dimensions | Not available |
| Country of Origin | France |
