20F1AND125JN0NNNNN
Product Type: AC Drive
Catalog Number: 20F1AND125JN0NNNNN
Series: PowerFlex 753
PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Open Type, 125 Amps, 100HP ND, 75HP HD, 480 VAC, 3 PH, Frame 6, Filtered, CM jumper installed (preferred), None, Blank (No HIM)
| Specification Category | Parameter |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Series | PowerFlex 753 |
| Enclosure Rating | Open Type / IP00 (NEMA Open) |
| Cooling Method | Air Cooled (Forced Air) |
| Input Voltage | 480V AC, 3-Phase |
| Frequency Range | 50 / 60 Hz |
| Rated Current (Output) | 125 Amps |
| Normal Duty Rating (ND) | 100 HP (75 kW) |
| Heavy Duty Rating (HD) | 75 HP (55 kW) |
| Heavy Duty Current | 96 Amps |
| Frame Size | Frame 6 |
| Dimensions (H x W x D) | 665.5 mm x 308 mm x 346.4 mm (approx. 26.2″ x 12.1″ x 13.6″) |
| Weight | Approx. 125.0 lbs (56.7 kg) |
| Interface Module | Blank (No HIM / No Control Element) |
| Internal I/O | Embedded I/O (Standard) |
| Communication | Dual-port EtherNet/IP (Optional – Ready) |
| DC Terminals | Not Included (No DC Terminals) |
| EMC Filtering | Filtered |
| CM Jumper | Removed (Common Mode Jumper Removed) |
| DB Transistor | Included (Dynamic Braking Transistor) |
| Ambient Temp (Operating) | 0 °C to 40 °C |
| Altitude | Up to 1000 m (without derating) |
| UPC | 889508554693 |
