| Parameter Item | Specification Value |
|---|---|
| Full MLFB Order Code | 6AV7882-0AA20-6CA0 |
| Product Model | SIMATIC IPC277E Compact Nanopanel Industrial PC |
| Display Spec | 7-inch TFT resistive single touch screen |
| Native Screen Resolution | 800 × 480 pixels |
| Backlight MTBF (25℃ Ambient) | 80,000 hours |
| Central Processing Unit | Intel Celeron N2807 (2-core/2-thread, 1.58GHz base, 2.16GHz burst) |
| Standard System RAM | 4GB DDR3L industrial memory |
| Built-in Storage Device | 240GB industrial MLC SATA SSD |
| Pre-installed Operating System | Windows 7 Ultimate SP1 64-bit Multi-language MUI (DE/EN/FR/ES/IT) |
| SIMATIC Runtime Software | Not pre-installed on delivery |
| Power Input Standard | Industrial 24V DC SELV power supply |
| Network Interfaces | 2 × Gigabit Ethernet RJ45 (PROFINET compatible) |
| Video Output Port | 1 × DisplayPort |
| USB Interfaces | 1 × USB3.0, 2 × USB2.0 rear ports |
| Serial Communication Port | 1 × RS232 COM1 |
| Expansion Slot | Built-in CFast memory card expansion slot |
| Front Panel Protection Class | IP65 dustproof & splash-proof |
| Rear Enclosure Protection Class | IP20 |
| Installation Type | Cabinet embedded panel mounting |
| Cabinet Cutout Size (W × H) | 190 mm × 130 mm |
| Overall Device Depth | 70 mm |
| Approximate Net Weight | 1.6 kg |
| Full-Load Operating Temp | 0 ℃ ~ +50 ℃ |
| Storage & Transit Temperature | -25 ℃ ~ +70 ℃ |
| Vibration Compliance Standard | IEC 60068-2-6 industrial vibration test |
| Shock Resistance Standard | IEC 60068-2-27 anti-shock specification for SSD configuration |
| Onboard Monitoring Functions | Hardware watchdog, temperature monitoring, SSD S.M.A.R.T. diagnosis |
| Product Lifecycle Status | PM410 product cancellation, production ceased since 01.06.2025 |
| Industrial Certifications | CE, UL, CSA, EAC, GL marine certification |
| MLFB Suffix Code Definition 6CA0 | 6=Win7 Ultimate 64-bit MUI; C=240GB internal SSD; A=No preloaded SIMATIC visualization software |
