6AV7260-4BA30-0CX0
SIMATIC IPC677D (Panel PC), 2×10/100/1000 Mbit/s Ethernet; 4x USB V3.0, 1x serial (COM1); Watchdog, temperature and Fan monitoring; RAID controller onboard; 19″ Multitouch (1366x 768) Celeron G1820TE (2C/2T, 2.2 GHz, 2 MB cache); PROFIBUS/MPI (CP 5622-compatible); 2 MB buffered SRAM 500 GB HDD SATA; 8 GB DDR3 1600 DIMM; 2x PCI without expansion (HW) Windows 10 Enterprise LTSB 2015, 64 bit, MUI (en, de, fr, it, es); without expansion (software) AC 110/230V industrial power supply unit with NAMUR; Power supply cable Europe
| Order Number | 6AV7260-4BA30-0CX0 |
| Product Name | SIMATIC IPC677D (Panel PC) |
| Ethernet | 2 × 10/100/1000 Mbit/s |
| USB Ports | 4 × USB 3.0 |
| Serial Port | 1 × serial (COM1) |
| Monitoring Functions | Watchdog, temperature monitoring, fan monitoring |
| RAID | RAID controller (onboard) |
| Display | 19″ multitouch, 1366 × 768 resolution |
| Processor | Intel Celeron G1820TE (2 cores / 2 threads, 2.2 GHz, 2 MB cache) |
| Fieldbus Interface | PROFIBUS/MPI (CP 5622‑compatible) |
| Buffered SRAM | 2 MB |
| Hard Disk Drive | 500 GB HDD, SATA interface |
| System Memory (RAM) | 8 GB DDR3 1600 DIMM |
| Expansion Slots (Hardware) | 2 × PCI (without expansion) |
| Operating System | Windows 10 Enterprise LTSB 2015, 64‑bit, MUI (English, German, French, Italian, Spanish) |
| Software Expansion | None (without expansion) |
| Power Supply | AC 110/230 V industrial power supply unit with NAMUR compliance |
| Power Cable | Power supply cable (Europe) |
| warranty | 1 YEAR |
| Net Weight (kg) | 17,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
