20G14NC085JA0NNNNN — PowerFlex Air Cooled 755 AC Drive
Allen‑Bradley PowerFlex 755 AC Drive, with Embedded Ethernet/IP, Standard Protection, Forced Air, DC Input with Precharge, IP20/IP00, NEMA/UL Open Type, 85 Amps, 45kW ND, 37kW HD, 400 VAC, 3 PH, Frame 5, Filtered, CM jumper installed (preferred), DB Transistor, Blank (No HIM)
| Manufacturer | Allen‑Bradley (Rockwell Automation) |
| Product Family | PowerFlex 755 |
| Type | AC Drive |
| Catalog Number | 20G14NC085JA0NNNNN |
| Communication Protocol | Embedded Ethernet/IP |
| Protection Rating (Enclosure) | Standard Protection |
| Cooling Method | Forced Air |
| DC Input Configuration | With Precharge |
| Ingress Protection (IP) Rating | IP20 / IP00 |
| NEMA/UL Enclosure Type | Open Type |
| Rated Current (Amps) | 85 A |
| Rated Power – Normal Duty (ND) | 45 kW |
| Rated Power – Heavy Duty (HD) | 37 kW |
| Input Voltage | 400 VAC |
| Input Phase | 3‑Phase (3 PH) |
| Frame Size | Frame 5 |
| EMC/RFI Filtering | Filtered |
| Common Mode (CM) Jumper | Installed (preferred configuration) |
| Dynamic Braking | DB Transistor (integrated) |
| Human Interface Module (HIM) | Blank (not supplied / no HIM fitted) |
