6AV7261-0GJ10-3CA0
| Parameter Item | Official Specification Value |
|---|---|
| Full Order Number | 6AV7261-0GJ10-3CA0 |
| Product Type | SIMATIC IPC677E Industrial Panel PC |
| Display | 19″ TFT projective-capacitive multi-touch, 1920×1080 Full HD |
| Backlight Lifespan | 50,000 hours MTBF at 25°C ambient temperature |
| Onboard Graphics | Integrated UHD Graphics 630; DP + DVI-D external display outputs |
| Ethernet Interfaces | 3 × Gigabit Industrial Ethernet / PROFINET |
| USB Interfaces | 6 × USB 3.1 Gen.2 |
| Serial Port | 1 × RS232 COM1 |
| Storage Controller | Onboard RAID controller (RAID0/1 supported, no pre-configured array) |
| System Monitoring | Hardware watchdog, CPU temperature & fan speed monitoring |
| CPU | Intel Core i7-8700 (6C/12T, 3.2GHz base / 4.6GHz turbo, 12MB cache, VT-d, AMT) |
| System Memory | 8 GB DDR4-2666 (1 × 8 GB single channel) |
| Internal Storage | Single 2.5″ SATA SSD, 480 GB (no RAID storage) |
| Power Input | 24 V DC industrial SELV power supply, NAMUR compliant |
| Pre-installed OS | Windows 10 Enterprise 2019 LTSC 64-bit, multi-language UI (en, de, fr, it, es) |
| TPM Security Module | Not equipped |
| Pre-installed SIMATIC Software | None |
| Expansion Slots | 2 PCIe slots (1 × PCIe x16, 1 × PCIe x4) |
| Protection Rating | Front IP65; rear housing IP20 |
| Installation Mode | Cabinet panel mounting, portrait mounting supported |
| Front Panel Size (W × H) | 475 mm × 363 mm |
| Cabinet Cutout Dimension | 460 mm × 252 mm |
| Unit Depth | 120 mm |
| Net Weight | Approx. 9.5 kg |
| Operating Temperature | 0 °C ~ +50 °C full load; derating required above 50°C |
| Storage & Transport Temp | -20 °C ~ +60 °C |
| Relative Humidity | 5% ~ 85% RH, non-condensing |
| Vibration Resistance (SSD) | 10–58 Hz: 0.0375 mm; 58–200 Hz: 9.8 m/s² |
| Shock Resistance (SSD) | 50 m/s², pulse duration 30 ms |
| Certifications | CE, cULus, RoHS 3, WEEE compliant |
| Lifecycle Status | PM300: Active production |
