6FX2001-5FN13
absolute encoder 6FX2001-5FN13 single-turn 16-bit with PROFINET operating voltage 10-30 V synchronous flange/ shaft 6 mm plug M12 radial FS15 maximum ambient temperature 85 °C
| Parameter | Specification |
|---|---|
| Article Number | 6FX2001-5FN13 |
| Product Description | Absolute encoder, single-turn 16-bit, PROFINET, 10-30 V, synchronous flange / shaft 6 mm, M12 plug radial, FS15, max. ambient temperature 85 °C |
| Product Family | Absolute encoders with PROFINET IO |
| Lifecycle | PM300: Active Product |
| Type | Single-turn absolute encoder |
| Resolution | 16-bit |
| Interface | PROFINET IO (Supports RT & IRT modes) |
| Supply Voltage | 10 – 30 V DC |
| Shaft Type | Synchronous flange / Solid shaft |
| Shaft Diameter | 6 mm |
| Shaft Length | 10 mm |
| Mechanical Mounting | Flange mount |
| Connection Type | M12 connector, radial |
| Max. Rotational Speed | 12,000 rpm |
| Max. Ambient Temperature | 85 °C |
| Min. Ambient Temperature | -40 °C |
| Protection Class | IP64, IP67 |
| Net Weight | 0.540 kg / 0.413 kg (varies by source) |
| Country of Origin | Germany |
