6AV7882-0BB10-1EA0 Full English Technical Parameter List (Strict Siemens Official Spec)
Basic Product Information
| Item | Parameter Value |
|---|---|
| MLFB Order No. | 6AV7882-0BB10-1EA0 |
| Product Family | SIMATIC IPC277E (Nanopanel Industrial Panel PC) |
| Lifecycle Status | PM410 – Discontinued since 09.08.2018 |
| Display | 9″ TFT, 800 × 480 (WVGA), analog resistive single-touch |
| Front Protection | IP65 / NEMA 4X |
| Rear Protection | IP20 |
| Backlight MTBF (25 °C) | 80,000 hours |
| Processor | Intel Celeron N2807, 2 cores / 2 threads |
| CPU Base / Burst Clock | 1.58 GHz / 2.16 GHz |
| L2 Cache | 1 MB |
| Graphics | Intel HD Graphics (integrated) |
| System RAM | 4 GB DDR3L (max. expandable to 8 GB) |
| Storage | 80 GB MLC industrial SATA SSD (replaceable) |
| Expansion Slot | CFast card slot |
| Ethernet | 2 × RJ45 Gigabit (10/100/1000 Mbps, PROFINET / Industrial Ethernet) |
| USB | 1 × USB 3.0 (rear), 2 × USB 2.0 (1 rear, 1 front service) |
| Serial Port | 1 × COM1 (RS232 / RS422 / RS485 configurable) |
| Video Output | 1 × DisplayPort |
| Operating System | Windows Embedded Standard 7E SP1, 32-bit, English |
| Pre-installed Runtime Software | None |
| Power Supply | 24 V DC (19.2–28.8 V DC tolerance) |
| Max. Power Consumption | 29 W (full load) |
| Front Panel Dimensions (W × H) | 274 mm × 190 mm |
| Depth | 73 mm |
| Mounting Cutout (W × H) | 254 mm × 170 mm |
| Net Weight | Approx. 1.8 kg |
| Operating Temperature (vertical) | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Relative Humidity | 5 %–90 % RH, non-condensing |
| Vibration | IEC 60068-2-6 compliant |
| Shock | IEC 60068-2-27 compliant |
| Certifications | CE, cULus, UKCA, RoHS |
| Country of Origin | Germany |
| ECCN | 5A992 |
