6AV7261-0CC10-2AB2
SIMATIC IPC677E(Panel PC), 19″ Multitouch (1920×1080); UHD graphic onboard; DP/DVI-D; 3x Gigabit Ethernet (IE/PN); 6x USB 3.1 Gen. 2; 1x serial (COM 1); RAID controller onboard; Watchdog, temperature and fan monitoring; Core i3-8100 (4C/4T, 3.6 GHz, 6 MB cache, VT-d); SSD 2.5″ SATA 480 GB internal; 8 GB DDR4-2666(2×4); 24 V DC industrial power supply Windows 10 Enterprise 2019 LTSC, 64-bit, MUI (en, de, fr, it, es) For Celeron and Core I3; Without extension (software); 2x USB 2.0 (1 slot occupied); 2x PCIe (x16, x4)
Product | |
Article Number (Market Facing Number) | 6AV7261-0CC10-2AB2 |
Product Description | SIMATIC IPC677E(Panel PC), 19″ Multitouch (1920×1080); UHD graphic onboard; DP/DVI-D; 3x Gigabit Ethernet (IE/PN); 6x USB 3.1 Gen. 2; 1x serial (COM 1); RAID controller onboard; Watchdog, temperature and fan monitoring; Core i3-8100 (4C/4T, 3.6 GHz, 6 MB cache, VT-d); SSD 2.5″ SATA 480 GB internal; 8 GB DDR4-2666(2×4); 24 V DC industrial power supply Windows 10 Enterprise 2019 LTSC, 64-bit, MUI (en, de, fr, it, es) For Celeron and Core I3; Without extension (software); 2x USB 2.0 (1 slot occupied); 2x PCIe (x16, x4) |
Series name | SIMATIC IPC677E |
Panel PC | |
Screen size | 19″ Multitouch |
Resolution ratio | 1920×1080 |
Processor type/CPU | Core i3-8100 |
Memory capacity | 8 GB DDR4-2666 |
Harddisk | 480 GB |
Operating system/OS | Windows 10 Enterprise 2019 LTSC |
Network Interface | 3x Gigabit Ethernet (IE/PN) |
Other interface | 6x USB 3.1 Gen. 2; 1x serial (COM 1) |
Power supply | 24 V DC |
Programming software | Without |
Warranty | 1 year |
Net Weight (kg) | 17.000 Kg |
Packaging Dimension | Not available |
Country of origin | Germany |
Quantity Unit | 1 Piece |
Packaging Quantity | 1 |
Additional Product Information | |
EAN | Not available |
UPC | 195125307735 |
Commodity Code | 84714100 |
LKZ_FDB/ CatalogID | ST80.1U |
Product Group | 4233 |
Group Code | R133 |
