ATV610C22N4



Part Nr: ATV610C22N4, 220kW, 350hp, 380 to 460V, IP00

Brand:   Type:
State:

Buy at DCS-Centers.com, Best price and Big Stock.

Item Specification
Part Number ATV610C22N4
Brand & Series Schneider Electric Easy Altivar 610 Variable Speed Drive
Supply 3-phase 380…460 VAC (-15% / +10%), 50/60 Hz
Normal Duty (ND) 220 kW / 350 HP; Continuous output current 403 A (2.5 kHz)
Heavy Duty (HD) 160 kW / 250 HP; Continuous output current 301 A (2.5 kHz)
Overload Capacity ND: 110% rated current for 60 s every 5 min; HD: 150% rated current for 60 s every 5 min
Control Mode V/F control, Sensorless vector control (open loop)
Output Frequency Range 0.1–500 Hz
Built-in Components Integrated DC choke; Integrated EMC Filter IEC/EN 61800-3 Category C3
PCB Protection Electronic boards with conformal coating
Protection Class IP20, cabinet mounting
Cooling Method Forced air cooling
Operating Temperature -15 °C ~ +45 °C (no derating); +45 °C ~ +60 °C (derating required)
Storage Temperature -40 °C ~ +70 °C
Ambient Class 3S2 dust, 3C2 chemical atmosphere (IEC 60721-3-3)
Onboard Communication Modbus RTU (RS485)
I/O Configuration 6 digital inputs, 3 analog inputs, 2 analog outputs, 3 relay outputs
Adjustable Switching Frequency 2…12 kHz (nominal 2.5 kHz)
Certifications CE, RoHS compliant
Embedded Functions Multi-pump rotation control, sleep mode, fire override, energy optimization

parts photo album​

ATV610C22N4, 220kW, 350hp, 380 to 460V, IP00
