1783-BMS10CGL
Stratix 5700 10 Port Managed Switch
| Specification | Detail |
| Part Number | 1783-BMS10CGL |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | Stratix 5700 |
| Description | Managed Industrial Ethernet Switch, Lite Firmware |
| Total Ports | 10 |
| Fast Ethernet Ports | 8 x 10/100 Mbps (RJ45, Copper) |
| Gigabit Combo Ports | 2 x 10/100/1000 Mbps (Supports either RJ45 Copper or SFP Fiber) |
| Firmware Type | Lite (Layer 2 Management) |
| Mounting | DIN Rail |
| Enclosure Rating | IP30 |
| Power Input | 12 to 48V DC (Class 2 or SELV Supply) |
| Current Range | 0.5 to 2.0 Amps |
| Max Power Consumption | 17 Watts |
| Operating Temperature | -40°C to +60°C (-40°F to +140°F) |
| Alarm Relay | Integrated (1A @ 30V DC / 0.5A @ 48V DC) |
| Dimensions (HxWxD) | Approx. 129.5 x 91.4 x 135.8 mm (5.1 x 3.6 x 5.3 in) |
| Weight | Approx. 1.11 kg (2.45 lbs) |
