Siemens 6SL3325-1TG33-3AA3 Parameter Table (English Version)
Note: All parameters are strictly based on Siemens official product catalog and technical manual, applicable for selection, quotation and technical solutions.
| Item (项目) | English Parameter |
| Order Number (订货号) | 6SL3325-1TG33-3AA3 |
| Product Series (产品系列) | SINAMICS S120 Cabinet-mounted Motor Module |
| Cooling Method (冷却方式) | Liquid Cooling |
| Protection Class (防护等级) | IP00 (Cabinet-mounted Type) |
| Frame Size (框架尺寸) | GXL |
| Product Status (产品状态) | Active (PM300: Active Product) |
| Origin (产地) | Germany |
| Net Weight (净重) | Approx. 80 kg |
| DC Input (直流输入) | 675–1035 V DC |
| AC Output (交流输出) | 500–690 V 3AC, 50/60 Hz |
| Rated Output Current (I₂N) (额定输出电流) | 330 A |
| Rated Output Power (额定输出功率) | 315 kW |
| Control Power Supply (控制电源) | 24 V DC (External Power Supply) |
| Output Frequency Range (输出频率范围) | 0–300 Hz (Standard), Extendable |
| Modulation Method (调制方式) | IGBT Self-commutated Inverter |
| DC Bus Connection (直流母线连接) | DCP / DCN (Busbar Connection) |
| Motor Output (电机输出) | Three-phase Busbar |
| DRIVE‑CLiQ Interface (DRIVE‑CLiQ 接口) | 3 pcs (for communication with control unit, encoder, etc.) |
| Temperature Sensor Input (温度传感器输入) | 1 channel (supports KTY84‑130, Pt1000, PTC, Pt100) |
| Safety Brake/Safety Integrated (安全制动/安全集成) | 1 channel (Safe Brake Adapter / Safety Integrated) |
| Coolant Interface (冷却介质接口) | 2 pcs (Inlet/Outlet) |
| Grounding (PE) (接地) | 2 positions |
| Status Indication (状态指示) | 3 LEDs (Running/Fault/Ready) |
| Height (H) (高度) | 1171 mm |
| Width (W) (宽度) | 150 mm |
| Depth (D) (深度) | 546 mm |
| Applicable Motors (适用电机) | Asynchronous Motor, Synchronous Motor, Servo Motor (with encoder required) |
| System Configuration (系统配置) | Requires S120 Control Unit (e.g., CU320‑2 PN) + Power Module (ALM/SLM/BLM) |
| Safety Functions (安全功能) | Supports STO (Safe Torque Off), SS1 and other Safety Integrated functions |
| Compliance & Certification (合规与认证) | RoHS Compliant (since 2018‑08‑01); Export Control: ECCN 3A999A; Complies with relevant IEC and EN industrial drive standards |
