6ES7647-6CE35-5AA0
| Parameter Item | Official Specification |
|---|---|
| Full Order Number | 6ES7647-6CE35-5AA0 |
| Product Model | SIMATIC IPC647C 19″ 2U Rack Industrial PC |
| Form Factor | 19-inch standard rack mount, 2 rack unit height |
| Processor | Intel Core i7-610E (2 Core / 4 Thread, 2.53 GHz Base, Turbo Boost, HT, VT-x, AMT, 4 MB Cache) |
| Chipset | Intel QM57 Express Chipset |
| Standard Main Memory | 4 GB DDR3-1066 Dual Channel SDRAM |
| Max Expandable RAM | 8 GB DDR3-1066 (Optional ECC memory available) |
| Mass Storage | 2 × 500 GB 3.5″ SATA Industrial Hard Disk, Vibration Damped, Support HW RAID 0/1 |
| Optical Drive | Slim-line DVD±R/RW Combo Drive |
| Onboard Graphics | Intel HD Integrated Graphics Controller, Rear DVI-I Interface |
| Display Output Support | DVI-I native, VGA via DVI-I adapter; Optional PCIe multi-display graphics card (up to 4 monitors) |
| Power Supply Type | Industrial AC Power Unit 100–240 VAC (-15% / +10%), NAMUR-compliant power failure buffering |
| Power Protection Class | Protection Class I per IEC 61140 |
| Front Panel Protection Rating | IP41 (closed door); Rear Side IP20 |
| Air Filtration | G2 Class air filter per EN 779, filters 99% particles >0.5 μm |
| Built-in Network Interfaces | 2 × 10/100/1000 Mbps Gigabit Ethernet RJ45 ports |
| Serial Communication Ports | 2 × RS232 COM ports, 1 × LPT parallel port |
| USB Interfaces Total | 7 × USB 2.0; 2 front panel, 4 rear panel, 1 internal onboard |
| Peripheral Ports | 2 × PS/2 (Keyboard & Mouse), Audio Line Out + Microphone In |
| Expansion Slots | 3-slot Bus Module: 1× PCI, 1× PCIe x8 (4 lanes), 1× PCIe x16 (occupied by onboard graphics) |
| System Monitoring Functions | Fan speed monitoring, CPU/Chassis temperature sensor, Hardware Watchdog Timer, Card retainer bracket |
| Vibration Resistance | 0.5 g continuous vibration; 5 g shock resistance |
| Operating Ambient Temperature | 5 °C to +40 °C (24/7 continuous full load operation) |
| Storage & Transport Temperature | -25 °C to +70 °C |
| Relative Humidity Range | 5% to 95% RH, non-condensing, non-corrosive atmosphere |
| Noise Level | ≤45 dB(A) at 25 °C (per DIN EN ISO 7779) |
| Overall Dimensions (W × H × D) | 430.4 mm × 88.1 mm × 444.4 mm |
| Unit Weight | 10 kg minimum, max 14 kg fully configured |
| Preinstalled Operating System | Windows 7 Professional 32-bit Multi-Language (DE/EN/FR/ES/IT), SP1 |
| Bundled Software | SIMATIC PC DiagMonitor V4.4 diagnostic tool |
| EMC Compliance Standards | EN 61000-6-2 (Industrial Immunity), EN 61000-6-3 (Emission), FCC Class A |
| Surge/Burst EMC Ratings | ±2 kV EFT Burst; ±1 kV Symmetric Surge; ±2 kV Asymmetric Surge (IEC 61000-4 series) |
| Global Certifications | CE, UL, CSA, RoHS compliant |
| Core Application Scenarios | WinCC Runtime Advanced, WinAC RTX, TIA Portal visualization, Industrial image processing, Data acquisition |
| Product Lifecycle | Discontinued legacy SIMATIC IPC647C series, spare parts available via Siemens service channel |
