6AV7250-8HD00-0HA0 SIMATIC IPC477D PRO, fully protected IP65
SIMATIC IPC477D PRO with 22-inch FHD touch screen, i7-3517UE CPU, 8GB RAM, 80GB SSD, PROFINET IRT & Gigabit Ethernet, RS232, 24V DC, no OS and preinstalled automation software.
| Parameter Item | Specification |
|---|---|
| Article Number (Market Facing Number) | 6AV7250-8HD00-0HA0 |
| Product Status | *** no longer available *** |
| Model Name | SIMATIC IPC477D PRO |
| Protection Class | Full IP65 protection |
| Display | 22″ multi-touch, resolution 1920 x 1080 |
| Mounting Design | Top flange, fitted for support arm, no expansion elements |
| USB Interface | 4 USB ports at rear, no front USB ports |
| Power Supply | 24 V DC industrial power supply |
| CPU | Core i7-3517UE, 2C/4T, base 1.7 GHz, max 2.8 GHz, 3 MB cache |
| System Memory | 8 GB |
| Storage | 80 GB SATA SSD, replaceable without drive |
| Network Interfaces | 1×Gbit Ethernet (IE/PN); 1×PROFINET IRT with 3 ports, 10/100/1000 Mbps |
| Serial Interface | 1×RS-232 |
| Operating System | Without operating system |
| SIMATIC Software | Without SIMATIC software |
