6SL3210-1PH22-7AL0
SINAMICS G120 POWER MODULE PM240-2 WITH BUILT IN CL. A FILTER WITH BUILT IN BRAKING CHOPPER 3AC500-690V +10/-20% 47-63HZ OUTPUT HIGH OVERLOAD: 18.5KW FOR 200% 3S,150% 57S,100% 240S AMBIENT TEMP -20 TO +50 DEG C (HO) OUTPUT LOW OVERLOAD: 22kW FOR 150% 3S,110% 57S,100% 240S AMBIENT TEMP -20 TO +40 DEG C (LO) 472 X 200 X 237 (HXWXD), FSD PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED FOR CU FIRMWARE- VERSION V4.7 HF8
| Order Number | 6SL3210-1PH22-7AL0 |
| Product Family | SINAMICS G120 |
| Product Type | Power Module PM240‑2 |
| Built‑in Components | • Class A line filter (integrated) • Braking chopper (integrated) |
| Input Voltage | 3 AC 500 – 690 V +10% / -20% |
| Input Frequency | 47 – 63 Hz |
| Output Power – High Overload (HO) | 18.5 kW • 200% for 3 s • 150% for 57 s • 100% for 240 s Ambient temp: –20 °C to +50 °C |
| Output Power – Low Overload (LO) | 22 kW • 150% for 3 s • 110% for 57 s • 100% for 240 s Ambient temp: –20 °C to +40 °C |
| Dimensions (H × W × D) | 472 × 200 × 237 mm |
| Frame Size | FSD |
| Degree of Protection | IP20 |
| Included Components | Without Control Unit and without Operator Panel (must be ordered separately) |
| Firmware Compatibility | Approved for Control Unit firmware version V4.7 HF8 and later (refer to compatibility notes) |
| Net Weight | 18.900 kg |
| Packaging Dimensions (W × H × D) | 356.00 × 495.00 × 300.00 mm |
| Country of Origin | Germany |
