| Category | Verified Specification for 6SE7027-2ED20 |
|---|---|
| MLFB Order Code | 6SE7027-2ED20 |
| Full Name | SIMOVERT MASTERDRIVES Vector Control Converter Compact Unit |
| Brand | Siemens |
| Country of Origin | Germany |
| Input Power Supply | 3AC 380–480 V (-10% / +10%), 50 / 60 Hz |
| Rated Power | 37 kW |
| Rated Continuous Output Current | 72 A |
| Enclosure Type | Compact Unit, IP20 |
| Control Platform | MASTERDRIVES VC Vector Control (general process drive) |
| Control Unit | CUVC control unit integrated inside compact frame |
| Communication Slots | 3 expansion slots for optional boards (PROFIBUS, encoder modules, SIMOLINK etc.) |
| Output Frequency Range | 0–600 Hz |
| Cooling Mode | Built-in forced air cooling |
| Mechanical Dimensions | W 220 mm × H 590 mm × D 385 mm |
| Net Weight | Approx. 32.5 kg |
| Mounting | Vertical wall mounting inside control cabinet |
| Operating Environment | Operating temperature: 0 °C … +40 °C full rating; derate above 40°C
Storage temperature: -40 °C … +70 °C Humidity: 5–95% non‑condensing, Pollution Degree 2 |
| Delivered scope | Base compact drive unit (no option boards included) + documentation CD |
| Certifications | CE, UL/cULus compliant |
| Lifecycle Status | Obsolete / End of production, only available as legacy spare part |
| Warranty | 1 Year standard manufacturer warranty |
| Packaging Note | Original single-unit export carton; outer carton dimensions not published in official datasheet. |
