Part number: 6SE7036-1EE85-0AA0. 6SE70361EE850AA0
Series:6SE70 SIMOVERT
Type: DC Converters
Description: SIMOVERT Master drives Infeed module Built-in unit/IP00 380-480 V 3 AC, 50/60 Hz 605 A
| Product Type | Common Rectifier / AC-DC Infeed Module (Passive, line-commutated) |
| Input Voltage (AC) | 3AC 380 – 480 V |
| Input Frequency | 50 / 60 Hz |
| Input Current (AC) | 526 A |
| Output Voltage (DC) | 510 – 620 V |
| Output Current (DC – Rated) | 605 A |
| Output Current (DC – Base Load) | 551 A |
| Output Current (DC – Short Time) | 823 A |
| Power Rating (Typical) | ~250 kW (at 400V class) |
| Operating Mode Class | Class I (Class II: 551A) |
| Weight | approx. 45 – 46 kg |
| Cooling Type | Forced Convection (Internal Fan) |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 46,00 Kg |
| Packaging Dimension | Not available |
| Country of origin | Austria |
| Quantity Unit | 1 Piece |
