6AV7260-1EB10-0AA0
SIMATIC IPC677D (Panel PC), 2×10/100/1000 Mbit/s Ethernet; 4x USB V3.0, 1x serial (COM1); Watchdog, temperature and Fan monitoring; RAID controller onboard; 19″ Touch (1366x 768); with front USB Core I3-4330TE (2C/4T, 2.4 GHz, 4 MB cache, VT-X); PROFIBUS/MPI CP 5622-compatible); 2 MB buffered SRAM 500 GB HDD SATA; DVD +/-RW; 2 GB DDR3 1600 DIMM; 2x PCI without expansion (HW) Windows 7 Ultimate 32 bit SP1, MUI (de, en, fr, es, it) SIMATIC IPC DiagMonitor enclosed AC 110/230V industrial power supply unit with NAMUR; Power supply cable Europe
| Order Number | 6AV7260-1EB10-0AA0 |
| Product Family | SIMATIC IPC677D (Panel PC) |
| Product Type | Industrial Panel PC |
| Ethernet Interfaces | 2 × 10/100/1000 Mbit/s Ethernet |
| USB Interfaces | 4 × USB V3.0 Front‑side USB interface included |
| Serial Interface | 1 × serial (COM1) |
| System Monitoring | Watchdog timer, temperature and fan monitoring |
| Storage Controller | RAID controller onboard |
| Display | 19″ Touch (1366 × 768) |
| Processor | Intel Core i3‑4330TE (2 cores / 4 threads, 2.4 GHz, 4 MB cache, VT‑x) |
| Fieldbus Interface | PROFIBUS / MPI (CP 5622‑compatible) |
| Retentive Memory | 2 MB buffered SRAM |
| Mass Storage | 500 GB SATA HDD |
| Optical Drive | DVD ± RW |
| System Memory (RAM) | 2 GB DDR3 1600 DIMM |
| Expansion Slots | 2 × PCI slots (free / available) |
| Hardware Expansions | Without additional hardware expansions (base configuration only) |
| Operating System | Windows 7 Ultimate 32‑bit SP1 MUI |
| Additional Software | SIMATIC IPC DiagMonitor (enclosed) |
| Power Supply | AC 110/230 V industrial power supply unit with NAMUR compliance (includes Europe power cable) |
| Net Weight | 17.000 kg |
| Packaging Dimensions | Not available |
| Country of Origin | Germany |
