6AG4131-3HQ20-3AA1
SIMATIC IPC627E (Box PC), UHD Graphics onboard; DP/DVI-D; 3x Gigbit Ethernet (IE/PN); 6x USB V3.1 Gen.2; 1x serial (COM 1); RAID controller onboard; Watchdog, temperature and fan monitoring; Core i7-8700 (6C/12T, 3.2(4.6) GHz, 12 MB cache, VT-d, AMT); NVRAM; M.2 SSD NVMe 512 GB; RAID1 2x SSD 2.5″ SATA 480 GB in removable frame; 16 GB DDR4-2666 (2×8); 24 V DC industrial power supply Windows 10 Enterprise 2019 LTSC, 64-bit, MUI (en, de, fr, it, es) For Core i7; without expansion (software); without expansion (HW); 1x PCIe (x16), 1x PCI
| Order No. | 6AG4131-3HQ20-3AA1 |
| Product Name | SIMATIC IPC627E (Box PC) |
| Graphics | UHD Graphics onboard; DP/DVI-D |
| Ethernet | 3x Gigabit Ethernet (IE/PN) |
| USB Ports | 6x USB V3.1 Gen.2 |
| Serial Ports | 1x serial (COM 1) |
| Integrated Controllers / Monitoring | RAID controller onboard; Watchdog, temperature and fan monitoring |
| Processor | Core i7-8700 (6C/12T, 3.2 (4.6) GHz, 12 MB cache, VT-d, AMT) |
| Memory Technology | NVRAM |
| Storage 1 (Primary) | M.2 SSD NVMe 512 GB |
| Storage 2 (RAID1) | RAID1 2x SSD 2.5″ SATA 480 GB in removable frame |
| RAM | 16 GB DDR4-2666 (2×8 GB) |
| Power Supply | 24 V DC industrial power supply |
| Operating System | Windows 10 Enterprise 2019 LTSC, 64-bit, MUI (en, de, fr, it, es) |
| Processor Note | For Core i7 |
| Software Expansion | without expansion (software) |
| Hardware Expansion | without expansion (HW) |
| Expansion Slots | 1x PCIe (x16), 1x PCI |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 6,00 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
