6BK1000-6MG01-1AA0
| Order Number | 6BK1000-6MG01-1AA0 |
| Platform | SIMATIC IPC627E |
| Processor (CPU) | Intel Core i3‑8100 (4 cores / 4 threads, 3.6 GHz, 6 MB cache, VT‑d) |
| System Memory (RAM) | 8 GB DDR4‑2666 (2 × 4 GB) |
| Mass Storage | • M.2 SSD NVMe 512 GB • 2.5″ SATA HDD 320 GB (internal) |
| Graphics | Intel UHD Graphics onboard; DisplayPort (DP) and DVI‑D interfaces |
| Networking | 3 × Gigabit Ethernet (IE/PN – Industrial Ethernet / PROFINET) ports |
| Ports & Interfaces | • 6 × USB 3.1 Gen.2 • 1 × Serial (COM 1) • RAID controller onboard |
| Monitoring & Security | Watchdog timer, internal temperature and fan monitoring |
| Power Supply | 24 V DC industrial power supply |
| Operating System | Windows 10 Enterprise 2016 LTSB (64‑bit, MUI) |
| Expansion Slots | 2 × PCIe (x16, x4) |
