6AG4131-2DB22-2BX6
SIMATIC IPC627D (Box PC), HD graphic onboard, 2x Gigabit Ethernet (IE/PN) 4xUSB V3.0; 1x serial (COM 1); RAID controller onboard; Watchdog, temp./fan monitoring Core I3-4330TE (2C/4T, 2.4 GHz, 4 MB cache, VT-X) 500 GB HDD SATA; DVD +/-RW; 4 GB DDR3 1600 DIMM; 1x PCIE (X16); 1x PCIE (X4) COM2; LPT (1 slot occupied) Windows 7 Ultimate 64 bit SP1, MUI (de, en, fr, es, it) without expansion (software) 24 V DC industrial Power supply
| Part Number | 6AG4131-2DB22-2BX6 |
| Product Name | SIMATIC IPC627D (Box PC) |
| Graphics | HD graphic onboard |
| Ethernet Interfaces | 2x Gigabit Ethernet (IE/PN) |
| USB Ports | 4x USB 3.0 |
| Serial Ports | 1x serial (COM 1) |
| Storage Controller | RAID controller onboard |
| Monitoring Features | Watchdog, temperature/fan monitoring |
| Processor | Core I3-4330TE (2 cores / 4 threads, 2.4 GHz, 4 MB cache, VT-x) |
| Storage | 500 GB HDD SATA |
| Optical Drive | DVD +/- RW |
| Memory (RAM) | 4 GB DDR3 1600 DIMM |
| Expansion Slots | 1x PCIe (x16); 1x PCIe (x4) |
| Additional Interfaces | COM2; LPT (1 slot occupied) |
| Operating System | Windows 7 Ultimate 64-bit SP1, MUI (de, en, fr, es, it) |
| Software Expansion | without expansion (software) |
| Power Supply | 24 V DC industrial power supply |
| Protection Level | 1 YEAR |
| Net Weight (kg) | 6,00 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
