7MB2001-1DA00-1AA1
OXYMAT 61 gas analyzer, 19″ rack unit for installation in cabinets Pipe with 1/4″ outer diameter 2 % reference gas supply with internal pump . . . AC 200 to 240 V, 48 to 63 Hz Without sample gas monitoring Without AUTOCAL function English
| Parameter Item | Official Exact Specification |
|---|---|
| Article / Part Number | 7MB2001-1DA00-1AA1 |
| Product Family | OXYMAT 61 Paramagnetic Oxygen Gas Analyzer |
| Core Measurement Principle | Paramagnetic oxygen detection (only for O₂ measurement) |
| Mounting Form | 19” rack unit, cabinet embedded installation |
| Sample Gas Pipe Connection | 1/4 inch outer diameter pipe interface |
| Internal Gas Pump | Equipped with built-in internal sampling pump |
| Reference Gas Configuration | 2% reference gas supply setup |
| Sample Gas Monitoring Function | Not equipped (Without sample gas monitoring) |
| Auto-Calibration Function | Not equipped (Without AUTOCAL function) |
| Operating Interface Language | English firmware & display |
| Power Supply Type | Alternating Current (AC) |
| Input Voltage Range | AC 200 V to 240 V |
| Operating Frequency Range | 48 Hz to 63 Hz |
| Net Weight | 14.500 kg |
| Country of Origin | France |
| Order Quantity Unit | 1 Piece per unit |
| Packaging Quantity | 1 unit per package |
| Packaging Dimension | Data not available |
| EAN Barcode | Not available |
| UPC Barcode | Not available |
| HS Commodity Code | 90271010 |
| Catalog ID (LKZ_FDB) | PA10 |
| Product Group Code | 4610 |
| Internal Group Code | R352 |
| Analog Output Definition (Suffix 1AA1) | Galvanically isolated 4–20 mA analog signal output; No PROFIBUS / HART digital bus expansion module |
