6SL3220-2YE28-0UP0 Specification(English Short Version)
Model：6SL3220-2YE28-0UP0 | Series: SINAMICS G120X
Model：6SL3220-2YE28-0UP0 | Series: SINAMICS G120X
| Item | Parameter |
|---|---|
| Rated Power | 15kW / 20HP |
| Input | 3AC 380~480V,47~63Hz |
| Rated Output Current | 29.5A |
| Max Output Current | 33A |
| Output Frequency | 0~550Hz |
| Overload Capacity | 110% for 60s |
| EMC Filter | Without built-in filter |
| Frame Size | FSC |
| Protection Grade | IP20 |
| Ambient Temp | -20℃ ~ +45℃ |
| Conformal Coating | 3C2 coating |
| Built-in Panel | BOP-2 operator panel |
| Onboard Communication | PROFINET, Modbus RTU, BACnet MS/TP, USS |
| DI/DO/AI/AO | 6DI,2Relay-DO,2AI,1AO |
| Mounting | Wall mounted |
| Dimension(H×W×D) | 295×140×209mm |
| Weight | 8.5kg |
| Certification | CE,UL,cUL,RoHS |
