Part Nr: SIEMENS 6DL1132-6BH00-0PH1 Input Module

Brand:   Type:
State:

Buy at DCS-Centers.com, Best price and Big Stock.

Parameter Specification
Model Number 6DL1132‑6BH00‑0PH1
Product Type Digital Output Module DQ 16 x 24 VDC / 0.5 A HA
Series SIMATIC ET 200SP HA
Number of Channels 16 channels, PNP (source output)
Rated Output Voltage 24 V DC
Rated Output Current per Channel 0.5 A
Max. Module Total Current 8 A
Residual Current (signal “0”) ≤0.7 mA
Switch‑on Delay (0→1) 50 µs typical
Switch‑off Delay (1→0) 100 µs typical
Max. Switching Frequency (resistive load) 100 Hz
Max. Switching Frequency (inductive load) 2 Hz
Lamp Load Capacity 5 W max per channel
Load Resistance Range 48 Ω … 12 kΩ
Short‑circuit & Overload Protection Yes, electronic channel‑wise protection
Channel Diagnostics Yes; short‑circuit, overload, wire‑break, supply monitoring
Redundancy Support Yes, compatible with M1‑type terminal block
Compatible Terminal Blocks H1, M1
Color Code CC02
Supply Voltage 19.2 V DC ~ 28.8 V DC
Power Consumption 1.8 W typical
CiR (Configuration in RUN) Parameterizable during RUN mode
I&M Data I&M0 to I&M3 supported
Firmware Field upgradable
Engineering Tool TIA Portal ≥V16, STEP7 V5.6, PCS7 ≥V9.0, PCS neo ≥V3.0
Communication Profile PROFINET, GSDML V2.3
Dimensions (W×H×D) 22.5 mm ×115 mm ×130 mm
Weight 0.3 kg
Operating Temperature ‑40 °C ~ +70 °C
Protection Class IP20 (module body)
Country of Origin Germany
