SIPLUS S7-300 CPU315F-2PN/DP -25 … +60 DEGREES C WITH CONFORMAL COATING BASED ON 6ES7315-2FJ14-0AB0 . CENTRAL PROCESSING UNIT WITH 512 KBYTE WORKING MEMORY, 1. INTERFACE MPI/DP 12MBIT/S, 2. INTERFACE ETHERNET PROFINET, WITH 2 PORT SWITCH, MICRO MEMORY CARD NECESSARY
6AG1315-2FJ14-2AB0 6AG1 315-2FJ14-2AB0 Siemens SIPLUS S7-300 CPU315F-2PN/DP
| Product | |
| Article Number (Market Facing Number) | 6AG1315-2FJ14-2AB0 |
| Product Description | SIPLUS S7-300 CPU315F-2PN/DP -25 … +60 DEGREES C WITH CONFORMAL COATING BASED ON 6ES7315-2FJ14-0AB0 . CENTRAL PROCESSING UNIT WITH 512 KBYTE WORKING MEMORY, 1. INTERFACE MPI/DP 12MBIT/S, 2. INTERFACE ETHERNET PROFINET, WITH 2 PORT SWITCH, MICRO MEMORY CARD NECESSARY |
| Product family | CPU 315F-2 PN/DP |
| Product Lifecycle (PLM) | PM300:Active Product |
| Price data | |
| Region Specific PriceGroup / Headquarter Price Group | 473 / 473 |
| List Price | Show prices |
| Customer Price | Show prices |
| Metal Factor | None |
| Delivery information | |
| Export Control Regulations | AL : N / ECCN : N |
| Standard lead time ex-works | 22 Day/Days |
| Net Weight (kg) | 0,525 Kg |
| Product Dimensions (W x L x H) | Not available |
| Packaging Dimension | 12,90 x 15,00 x 5,10 |
| Package size unit of measure | CM |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Category | Core Specifications | Key Notes |
|---|---|---|
| Basic Product Info | Order No.: 6AG1315-2FJ14-2AB0 Model: SIPLUS CPU 315F-2 PN/DP Base standard model: 6ES7315-2FJ14-0AB0 Series: SIPLUS S7-300 (Conformal coated) Firmware: V3.2 Safety Cert: SIL3 / PL e Cat.4 |
SIPLUS enhanced rugged version with PCB protective coating for harsh industrial environments |
| Memory Configuration | Work memory: 512 KB Retentive memory: 128 KB Load memory: Max 8MB MMC (mandatory) Data retention: ≥10 years, no backup battery |
Independent memory partition for safety & standard control logic |
| CPU Execution Speed | Bit logic: 0.05 µs Word compare: 0.09 µs 32-bit float multiplication: 0.45 µs Process image: 384B Input / 384B Output |
Fast loop response for safety critical motion & process control |
| Integrated Communication Ports | 1. MPI/PROFIBUS-DP (RS485, 12Mbps, max 32 DP slaves) 2. 2-port PROFINET 10/100Mbps switch Supported protocols: PROFIsafe V2.6, S7, ISO-on-TCP, UDP, Web Server Max PN IO devices:128; Max S7 connections:16 |
Native fail-safe communication for distributed F-I/O |
| I/O Expansion Capacity | Max total modules: 32 (4 racks max) Max digital I/O:1024 DI / 1024 DO Max analog I/O:256 AI / 256 AO Max safety F-I/O channels:1024 Distributed I/O limit: 2048 points (DP & PN each) |
Supports mixed standard & safety distributed I/O stations |
| Electrical Parameters | Supply: 24VDC (20.4~28.8V DC) Rated operating current:750mA Typical power loss:4.65W Voltage hold-up time:5ms Recommended external fuse:2A DC |
Same electrical rating as standard 6ES7 base model |
| Mechanical & SIPLUS Environmental Specs | Dimension:40(W)×125(H)×130(D) mm Net weight:399g Mount: DIN rail EN 50022, IP20 Coating: Full conformal PCB protection Operating temp: -25°C ~ +60°C (horizontal) Storage temp: -40°C ~ +85°C Humidity:5~95% RH non-condensing |
Wider low-temperature range vs standard S7-300 CPU; anti-corrosion coating for dust/humid industrial sites |
| Safety Core Functions | PROFIsafe safety communication Independent safety runtime partition Auto safety program integrity check Safe reaction time ≤20ms Dedicated safety diagnostic buffer |
Compliant with IEC 61508 & EN ISO 13849 machinery safety standards |
