variable speed drive ATV610 – 55 kW/75 HP – 380…415 V – IP20
ATV610D55N4
| Main | |
| Range of product | Easy Altivar 610 |
| Product specific application | Fan, pump, compressor, conveyor |
| Product or component type | Variable speed drive |
| Device short name | ATV610 |
| Variant | Standard version |
| Product destination | Asynchronous motors |
| Synchronous motors | |
| Mounting mode | Cabinet mount |
| EMC filter | Integrated conforming to IEC 61800-3 category C3 with 50 m |
| IP degree of protection | IP20 |
| Type of cooling | Forced convection |
| Supply frequency | 50…60 Hz +/-5 % |
| Network number of phases | 3 phases |
| [Us] rated supply voltage | 380…460 V – 15…10 % |
| Motor power kW | 55 kW for normal duty |
| 45 kW for heavy duty | |
| Motor power hp | 75 hp for normal duty |
| 60 hp for heavy duty | |
| Line current | 111.5 A at 380 V (normal duty) |
| 99.7 A at 460 V (normal duty) | |
| 95.9 A at 380 V (heavy duty) | |
| 84.0 A at 460 V (heavy duty) | |
| Prospective line Isc | 22 kA |
| Apparent power | 79.5 kVA at 460 V (normal duty) |
| 66.9 kVA at 460 V (heavy duty) | |
| Continuous output current | 88 A at 2.5 kHz for heavy duty |
| 120 A at 2.5 kHz for normal duty | |
| Maximum transient current | 132 A during 60 s (heavy duty) |
| 132 A during 60 s (normal duty) | |
| Asynchronous motor control profile | Optimized torque mode |
| Constant torque standard | |
| Variable torque standard | |
| Output frequency | 0.1…500 Hz |
| Nominal switching frequency | 2.5 kHz |
| Switching frequency | 1…8 kHz adjustable |
| number of preset speeds | 16 preset speeds |
| Communication port protocol | Modbus serial |
| Option card | Slot A: communication card, Profibus DP V1 |
| Slot A: digital or analog I/O extension card | |
| Slot A: relay output card | |
| Complementary | |
| Output voltage | <= power supply voltage |
| Motor slip compensation | Automatic whatever the load |
| Adjustable | |
| Not available in permanent magnet motor law | |
| Can be suppressed | |
| Acceleration and deceleration ramps | S, U or customized |
| Linear adjustable separately from 0.01 to 9000 s | |
| Braking to standstill | By DC injection |
| Frequency resolution | Display unit: 0.1 Hz |
| Analog input: 0.012/50 Hz | |
| Electrical connection | Control, screw terminal: 0.5…1.5 mm² |
| Line side, screw terminal: 70…120 mm² | |
| Motor, screw terminal: 70…120 mm² | |
| Connector type | 1 RJ45 (on the remote graphic terminal) for Modbus serial |
| Physical interface | 2-wire RS 485 for Modbus serial |
| Transmission frame | RTU for Modbus serial |
| Transmission rate | 4.8, 9.6, 19.2, 38.4 kbit/s for Modbus serial |
| Type of polarization | No impedance for Modbus serial |
| Number of addresses | 1…247 for Modbus serial |
| Method of access | Slave |
| Supply | External supply for digital inputs: 24 V DC (19…30 V), <1.25 mA, protection type: overload and short-circuit protection |
| Internal supply for reference potentiometer (1 to 10 kOhm): 10.5 V DC +/- 5 %, <10 mA, protection type: overload and short-circuit protection | |
| Width | 290 mm |
| Depth | 323 mm |
| Net weight | 53 kg |
| Analogue input number | 3 |
| Environment | |
| Noise level | 78 dB conforming to 86/188/EEC |
| Power dissipation in W | 969 W(forced convection) at 380 V, switching frequency 2.5 kHz |
| 131 W(natural convection) at 380 V, switching frequency 2.5 kHz | |
| Volume of cooling air | 295 m3/h |
| Operating position | Vertical +/- 10 degree |
| Pollution degree | 2 conforming to IEC 61800-5-1 |
| Vibration resistance | 1.5 mm peak to peak (f= 2…13 Hz) conforming to IEC 60068-2-6 |
| 1 gn (f= 13…200 Hz) conforming to IEC 60068-2-6 | |
| Shock resistance | 15 gn for 11 ms conforming to IEC 60068-2-27 |
| Relative humidity | 5…95 % without condensation conforming to IEC 60068-2-3 |
| Ambient air temperature for operation | -15…45 °C (without derating) |
| 45…60 °C (with derating factor) | |
| Ambient air temperature for storage | -40…70 °C |
| Operating altitude | <= 1000 m without derating |
| 1000…4800 m with current derating 1 % per 100 m | |
