| General Information |
Model Number |
ATV630C22N4 |
|
Brand |
Schneider Electric |
|
Product Series |
Altivar Process ATV630 Variable Speed Drive (VFD/VSD) |
|
Applicable Load |
3-phase asynchronous / synchronous AC motor |
|
Country of Origin |
China |
| Input Electrical Specifications |
Input Phase |
3-phase AC |
|
Rated Supply Voltage |
380 V ~ 480 V AC |
|
Voltage Tolerance Range |
-15% / +10% of rated voltage |
|
Supply Frequency |
50 Hz / 60 Hz ±5% |
|
Normal Duty Line Current (380V / 480V) |
397 A / 324 A |
|
Heavy Duty Line Current (380V / 480V) |
296 A / 246 A |
|
Prospective Short-Circuit Current (Isc) |
50 kA |
| Output Power Ratings |
Normal Duty (ND) Motor Power |
220 kW / 350 HP, 120% overload for 60 seconds |
|
Heavy Duty (HD) Motor Power |
160 kW / 250 HP, 150% overload for 60 seconds |
|
Continuous Output Current (2.5kHz carrier, ND) |
427 A |
|
Continuous Output Current (2.5kHz carrier, HD) |
302 A |
|
Maximum Transient Output Current (ND 60s) |
470 A |
|
Maximum Transient Output Current (HD 60s) |
453 A |
|
Maximum Output Frequency |
0 Hz ~ 500 Hz |
|
Adjustable Carrier Frequency |
2.5 kHz / 4 kHz / 8 kHz / 12 kHz |
|
Normal Duty Apparent Power (480V) |
247 kVA |
|
Heavy Duty Apparent Power (480V) |
187 kVA |
| Safety & Protection |
Integrated Safety Function |
Built-in Safe Torque Off (STO) (STOA / STOB safety inputs) |
|
Protection Functions |
Overcurrent, overvoltage, undervoltage, overtemperature, motor overload, short circuit, earth fault, phase loss detection |
|
Safety Compliance Standard |
IEC 61508 SIL2, IEC 61511 |
| Control I/O Interfaces |
Digital Inputs |
6 standard digital inputs (DI1~DI6) + 2 STO safety inputs; Sink/Source logic selectable |
|
Analog Inputs |
3 analog inputs (configurable 0–10V / 0–20mA) |
|
Analog Outputs |
2 analog outputs (configurable 0–10V / 0–20mA, 10-bit resolution) |
|
Relay Outputs |
2 configurable relay contact outputs (R1, R2) |
|
Control Terminal Wire Gauge |
0.5 mm² ~ 1.5 mm² (AWG20 ~ AWG14) |
| Communication Interfaces |
Standard Built-in Ports |
1 × Ethernet RJ45 port; 2 × Modbus RS45 serial ports |
|
Standard Supported Protocols |
Modbus RTU, Modbus TCP |
|
Optional Communication Cards |
PROFINET, PROFIBUS DP, EtherNet/IP, CANopen, BACnet MS/TP, DeviceNet |
|
Serial Communication Baud Rate |
4800 / 9600 / 19200 / 38400 bps |
|
Ethernet Communication Speed |
10/100 Mbps |
| Mechanical & Cooling |
Cooling Type |
Forced air convection cooling |
|
Standard Protection Grade |
IP00 (chassis type); IP21 optional with VW3A9112 installation kit |
|
Mounting Method |
Wall-mounted chassis installation |
|
Overall Dimensions (W × H × D) |
440 mm × 1195 mm × 377 mm |
|
Net Weight |
172 kg |
| Environmental Conditions |
Operating Temperature Range |
-10 °C ~ +50 °C (output derating required above 40 °C) |
|
Storage & Transport Temperature |
-25 °C ~ +70 °C |
|
Ambient Relative Humidity |
5% ~ 95% RH, non-condensing |
|
Vibration Compliance Standard |
IEC 60068-2-6 |
| Certifications & Compliance |
Official Approvals |
CE, UL 508C, CSA, TÜV, DNV GL, ATEX |
|
EMC Compliance Class |
Class C2 (per EN/IEC 61800-3) |
|
Environmental Compliance |
RoHS 3 compliant |
| Built-in Core Functions |
1. Embedded power monitoring & energy consumption dashboard |
|
|
2. Stop & Go low-energy standby mode |
|
|
3. Asset drift monitoring & predictive maintenance alerts |
|
|
4. Integrated PID process closed-loop control |
|
|
5. Pump/fan sleep mode & multi-motor switching logic |
|
|
6. Fire mode, flying restart, rotating load catch function |
|
|
7. Energy saving curve & operation data logging |
|
| Model Code Definition |
ATV630 |
Altivar Process series heavy-duty process variable speed drive |
|
C22 |
220 kW normal duty power rating |
|
N4 |
3-phase 380V ~ 480V AC input voltage grade |
