4PP420.0571
| Category | Parameter | Specification |
| General | Model | 4PP420.0571 (Power Panel 400) |
| Processor | Geode LX800, 500 MHz, 32-bit x86 | |
| Operating System | Automation Runtime | |
| Display | Size / Type | 5.7″ (144 mm) / QVGA |
| Resolution | 320 x 240 pixels | |
| Colors | 8 shades of gray, 512 colors, or 262,144 colors (variant dependent) | |
| Touch Screen | Analog resistive | |
| Memory | RAM | 128 MB DDR SDRAM |
| Flash (Firmware) | 2 MB | |
| SRAM | 512 kB (battery-buffered) | |
| Interfaces | Ethernet | 1x 10/100 Mbit/s (RJ45) |
| Serial | 1x RS232 (9-pin DSUB, max. 115 kBaud) | |
| USB | 2x (USB 1.1 & 2.0, max. 500 mA per connection) | |
| Expansion | 1x aPCI slot | |
| Storage | 1x CompactFlash slot (Type I) | |
| Electrical | Power Supply | 18 – 30 VDC |
| Rated Current | 0.5 A | |
| Power Consumption | Typically 12 W | |
| Mechanical | Dimensions (W x H x D) | 212 x 156 x 76 mm |
| Weight | Approx. 1.7 kg | |
| Housing / Frame | Metal / Naturally anodized aluminum | |
| Environmental | Protection Rating | Front: IP65 / NEMA 250 Type 4X; Rear: IP20 |
| Operating Temperature | 0 to +50 °C | |
| Storage Temperature | -20 to +70 °C | |
| Max. Altitude | 3000 m (with temperature derating above 500 m) |
