ACS880-11-101A-5
General Information
-
-
- Global Commercial Alias:
- ACS880-11-101A-5
-
- Product ID:
- 3AXD50000047395
-
- ABB Type Designation:
- ACS880-11-101A-5
-
- EAN:
- 6438177547952
-
- Catalog Description:
- ACS880-11-101A-5 PN: 55 kW, IN: 101 A
-
- Long Description:
- The ACS880-11 drives are customized to meet the particular needs of specific industries, such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. They can control a wide range of applications, including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps and fans. The ACS880-11 is a compact and complete regenerative drive solution with everything you need for regenerative operation in cyclic or continuous braking applications.
With regenerative functionality, the braking energy of the motor is returned to the drive and distributed to the supply network so that it can be utilized by other equipment. With mechanical or resistor braking energy is wasted as heat and additional cooling is often required, whereas regenerative drive operation offers significant savings in energy consumption and cooling. The drive reaches a unity power factor, meaning that electrical energy is used to its full potential. Equipped with an active supply unit and integrated low harmonic line filter, the regenerative drive produces exceptionally low harmonic content.
-
-
- Country of Origin:
- Finland (FI)
-
- Customs Tariff Number:
- 85044084
-
- Invoice Description:
- ACS880-11-101A-5 PN: 55 kW, IN: 101 A
-
- Made To Order:
- Yes
-
- Minimum Order Quantity:
- 1 piece
-
- Order Multiple:
- 1 piece
-
- Quote Only:
- No
-
- Selling Unit of Measure:
- piece
Container Information
-
- Gross Volume:
- 124.485 dm³
Dimensions
-
- Product Net Weight:
- 102 kg
-
- Product Net Height:
- 965 mm
-
- Product Net Length:
- 430 mm
-
- Product Net Width:
- 300 mm
-
- Package Level 1 Depth / Length:
- 660 mm
-
- Package Level 1 Height:
- 1150 mm
-
- Package Level 1 Width:
- 500 mm
-
- Package Level 1 Units:
- 1 carton
Technical
-
- Number of Phases:
- 3
-
- Degree of Protection:
- IP21
-
- Enclosure Type NEMA:
- Type1
-
- Frequency (f):
- 50/60 Hz
-
- Input Voltage (Uin):
- 380 … 500 V
-
- Mounting Type:
- Wall-mounted
-
- Communication Protocol:
- MODBUS
DeviceNet
PROFIBUS
PROFIsafe
CAN
EtherNet/IP
PROFINET IO
TCP/IP
Other Bus Systems
-
- Number of Hardware Interfaces:
- Industrial Ethernet 0
PROFINET 0
RS-232 0
RS-422 0
RS-485 1
Serial TTY 0
USB 1
Parallel 0
Other 6
-
- Includes:
- With control unit
Without optical interface
With PC connection
-
- Analog Inputs:
- 2
-
- Analog Outputs:
- 2
-
- Number of Digital In/Outputs:
- 6/5
-
- Output Current, Heavy-Duty Use:
- 77 A
-
- Output Current, Light-Overload Use:
- 91 A
-
- Output Current, Normal Use:
- 101 A
-
- Output Power, Heavy-Duty Use:
- 45.0 kW
-
- Output Power, Light-Overload Use:
- 55.0 kW
-
- Output Power, Normal Use:
- 55.0 kW
-
- Ecodesign Exemption:
- Energy efficiency data is not provided for the drive. The regenerative drives are exempt from the EU ecodesign requirements (Regulation EU/2019/1781, §2.3.c).
Additional Information
-
- Product Main Type:
- ACS880-11
-
- Product Name:
- Frequency converter
Classifications
-
- ETIM 7:
- EC001857 – Frequency converter =< 1 kV
-
- UNSPSC:
- 39122001
Environmental
-
- SCIP:
- a8974b22-8596-4130-8a8f-51671d307fb7 Finland (FI)
-
- WEEE Category:
- 4. Large Equipment (Any External Dimension More Than 50 cm)
