ACS580-04-880A-4
General Information
-
- Global Commercial Alias:
- ACS580-04-880A-4
-
- Product ID:
- 3AUA0000170525
-
- ABB Type Designation:
- ACS580-04-880A-4
-
- EAN:
- 6438177340478
-
- Catalog Description:
- ACS580-04-880A-4 PN: 500 kW, IN: 880 A
-
- Long Description:
- The ACS580-04 is plug-in ready to control your compressors, conveyors, pumps, extruders, centrifuges, mixers, fans and many other variable and constant torque applications, in a variety of light industries, including food and beverage, plastic, textile, material handling, and agriculture.
All essential features are built-in as standard, simplifying drive selection, and making additional hardware unnecessary. Versatile and straightforward settings menu and assistants enable fast setup, commissioning, use and maintenance, while rugged and robust design makes it a good fit for various environments. With the ACS580 drives you can easily take full control of your processes to comprehensively manage your plant. The ACS580-04 drive module comes in IP00 enclosure as standard for cabinet installation. Also, IP20 enclosure is available.
-
- Country of Origin:
- Finland (FI)
-
- Customs Tariff Number:
- 85044088
-
- Invoice Description:
- ACS580-04-880A-4 PN: 500 kW, IN: 880 A
-
- Made To Order:
- Yes
-
- Minimum Order Quantity:
- 1 piece
-
- Order Multiple:
- 1 piece
-
- Quote Only:
- No
-
- Selling Unit of Measure:
- piece
Container Information
-
- Gross Volume:
- 0.19 m³
Dimensions
-
- Product Net Weight:
- 200 kg
-
- Product Net Height:
- 1662 mm
-
- Product Net Length:
- 529 mm
-
- Product Net Width:
- 350 mm
-
- Package Level 1 Depth / Length:
- 2060 mm
-
- Package Level 1 Height:
- 500 mm
-
- Package Level 1 Width:
- 670 mm
-
- Package Level 1 Units:
- 1 carton
Technical
-
- Number of Phases:
- 3
-
- Degree of Protection:
- IP00
-
- Enclosure Type NEMA:
- Open Type
-
- Frequency (f):
- 50/60 Hz
-
- Input Voltage (Uin):
- 380 … 480 V
-
- Mounting Type:
- Module for cabinet building
-
- Output Current, Heavy-Duty Use:
- 725 A
-
- Output Current, Light-Overload Use:
- 865 A
-
- Output Current, Normal Use:
- 880 A
-
- Output Power, Heavy-Duty Use:
- 400 kW
-
- Output Power, Light-Overload Use:
- 500 kW
-
- Output Power, Normal Use:
- 500 kW
-
- Apparent Power Output:
- 610 kV·A
-
- Efficiency Level:
- IE2
-
- Standby Loss:
- 575 W
-
- Complete Drive Module Efficiency (61800-9-2):
-
Operating Point Frequency / Current Absolute Loss Relative Loss Efficiency 0 / 25 % 2773 W 0.5 % 92.1 % 0 / 50 % 4008 W 0.7 % 94.1 % 0 / 100 % 7468 W 1.2 % 94.5 % 50 / 25 % 3002 W 0.5 % 95.8 % 50 / 50 % 4515 W 0.7 % 96.7 % 50 / 100 % 8712 W 1.4 % 96.8 % 90 / 50 % 5260 W 0.9 % 97.9 % 90 / 100 % 10874 W 1.8 % 97.8 %
-
- Temperature Rating:
- Maximum 40 °C
Additional Information
-
- Product Main Type:
- ACS580-04
-
- Product Name:
- Frequency converter
Classifications
-
- UNSPSC:
- 39122001
Environmental
-
- SCIP:
- e9fd22a6-81c4-4079-87c1-83e8cf566d7a Finland (FI)
-
- WEEE Category:
- 4. Large Equipment (Any External Dimension More Than 50 cm)
