ATV630U55N4



Part Nr: ATV630U55N4 ATV630, 5.5kW, 7.5hp, 380 to 480V, IP21

Brand:   Type:
State:

Buy at DCS-Centers.com, Best price and Big Stock.

Core Electrical Parameters (3‑phase, 380–480 V AC)

Parameter Normal Duty (120% overload, 60 s) Heavy Duty (150% overload, 60 s) Unit Notes
Motor Power 5.5 / 7.5 4.0 / 5.0 kW / hp
Apparent Power (480 V) 7.6 6.0 kVA
Supply Voltage 380–480 380–480 V AC 3‑phase, −15% / +10% tolerance
Supply Frequency 50/60 ±5 50/60 ±5 Hz
Input Line Current (380 V) 10.4 8.0 A
Input Line Current (480 V) 9.1 7.2 A
Continuous Output Current (4 kHz) 12.7 9.3 A
Max Transient Current (60 s) 14.0 11.2 A
Output Frequency Range 0.0001–599 0.0001–599 Hz
Nominal Switching Frequency 4 4 kHz
Adjustable Switching Frequency 2–12 2–12 kHz 4–12 kHz with derating
Prospective Short‑circuit Current (Isc) 50 50 kA Line side
STO (Safe Torque Off) SIL 3 SIL 3 Safety rating

Mechanical & Environmental

Parameter Value Unit
Dimensions (W×H×D) 144 × 350 × 203 mm
Weight 4.7 kg
Enclosure IP21 / NEMA Type 1
Operating Temperature −15 to +50 °C
Altitude ≤ 1000 (no derating); 1000–4800 (1% derating per 100 m) m
Cooling Forced convection

Communication & Features

Parameter Value
Ports 1 × Ethernet, 2 × serial (Modbus), 3 × RJ45
Protocols Modbus TCP, Modbus RTU
Built‑in EMC filter (C2/C3), power measurement, energy dashboard
Digital Inputs 6 programmable (24 V DC), 2 STO inputs
Analog I/O 2 analog inputs, 1 analog output
Relay Outputs 3 programmable relays

parts photo album​
