| Parameter Category | Parameter Name | Value & Specification |
|---|---|---|
| General Information | Model | ATV630U22N4 |
| Series | Altivar Process ATV630 | |
| Supply Phases | 3‑phase AC | |
| Mounting | Wall‑mount, vertical orientation | |
| Power & Rating | Motor Power (Normal Duty) | 2.2 kW / 3 HP |
| Motor Power (Heavy Duty) | 1.5 kW / 2 HP | |
| Rated Supply Voltage | 380…480 VAC (−15…+10% tolerance) | |
| Supply Frequency | 50…60 Hz (−5…+5% tolerance) | |
| Line Current (Normal Duty) | 4.3 A @ 380 VAC; 3.8 A @ 480 VAC | |
| Line Current (Heavy Duty) | 3.1 A @ 380 VAC; 2.9 A @ 480 VAC | |
| Continuous Output Current | 5.6 A (4 kHz switching frequency, normal duty) | |
| Continuous Output Current | 4.0 A (4 kHz switching frequency, heavy duty) | |
| Max. Transient Current | 6.2 A (60 s, normal duty); 6.0 A (60 s, heavy duty) | |
| Apparent Power (Normal Duty, 480 VAC) | 3.2 kVA | |
| Apparent Power (Heavy Duty, 480 VAC) | 2.4 kVA | |
| Prospective Short‑Circuit Current (Isc) | 50 kA | |
| Output Performance | Output Frequency Range | 0.0001…500 Hz |
| Nominal Switching Frequency | 4 kHz | |
| Adjustable Switching Frequency | 2…12 kHz | |
| Control Modes | V/F, Sensorless Vector, Flux Vector | |
| Max. Output Voltage | ≤ supply voltage (380…480 VAC) | |
| Motor Compatibility | Asynchronous, permanent magnet, synchronous reluctance | |
| Protection & Safety | Degree of Protection | IP21 (IEC 60529); UL Type 1 (UL 508C) |
| Safety Functions | STO (Safe Torque Off) to SIL 3; optional SLS, SS2, SLP | |
| Short‑Circuit Protection | Integrated | |
| Motor Overload Protection | Thermal motor model (IEC 61800‑5‑1) | |
| Overvoltage / Undervoltage | Line‑side monitoring | |
| EMC Immunity | Level 3 (IEC 61000‑4‑2,‑4‑3,‑4‑5,‑4‑8,‑4‑11) | |
| EMC Emission | C2 (IEC 61800‑3); C3 (environment 2) | |
| Environment & Physical | Operating Temperature | −15…50 °C (no derating); −15…60 °C (derated) |
| Storage / Transport Temperature | −40…70 °C | |
| Operating Altitude | ≤ 1000 m (no derating); > 1000 m (derating required) | |
| Vibration Resistance | 1 gn (13…200 Hz); 1.5 mm p‑p (2…13 Hz) (IEC 60068‑2‑6) | |
| Cooling | Forced convection (38 m³/h airflow) | |
| Dimensions (W × H × D) | 144 mm × 350 mm × 203 mm | |
| Weight | Approx. 6 kg (13.2 lbs) | |
| Communication & I/O | Standard Communication | Modbus RTU (RS‑485), Ethernet, Modbus TCP |
| Discrete Inputs | 8 configurable | |
| Analog Inputs | 3 (0…10 VDC / 0…20 mA / 4…20 mA; PTC, Pt100/1000, KTY84) | |
| Analog Outputs | 2 (0…10 VDC / 0…20 mA) | |
| Relay Outputs | 3 | |
| Preset Speeds | 16 user‑definable | |
| Certifications & Standards | Approvals | CE, CSA, UL, cUL, EAC, ATEX (Zone 2/22), DNV‑GL |
| Standards | IEC 61000‑3‑12, IEC 61508, IEC 60721‑3, EN ISO 13849‑1, IEC 61800‑5/-12/-51 |
