| Product Identification |
Part Number |
6ES7647-6BH30-0AX0 |
Official Siemens Order Number |
|
Product Name |
SIMATIC Box PC 627B |
Industrial Automation PC |
|
Series |
SIMATIC Box PC 627 |
Siemens Industrial PC Family |
| Power Supply (Dual Version) |
Primary Power (AC) |
AC 100–240 V (-15% / +10%), autorange |
NAMUR-compliant (short-term power fail bridging) |
|
AC Frequency |
50–60 Hz (47–63 Hz) |
Wide frequency tolerance for industrial grids |
|
AC Power Fail Bridging |
Max. 20 ms (at 93 V or 264 V) |
Ensures data integrity during brief outages |
|
AC Power Rating |
190 W (Nominal) |
Typical operating power consumption |
|
Optional Power (DC) |
24 V DC (-15% / +20%), SELV |
Isolated low-voltage version (210 W) |
| Current & Power Details |
AC Input Current (Nominal) |
~2.3 A (at 110 V) / ~1.15 A (at 230 V) |
Steady-state; peak inrush < 50 A for 1 ms |
|
DC Output Rails |
+5 V / 16.5 A (18.5 W peak); +3.3 V / 8.5 A; +12 V / 6.5 A (8 A peak); -12 V / 0.3 A |
Total DC output ≤ 150 W (sum of all rails) |
|
Max Continuous Current |
9 A (system total); 14 A for 30 ms (startup surge) |
For worst-case peripheral loading |
| Processor & Memory |
Processor |
Intel Core 2 Duo T7400 |
2.16 GHz, 4 MB L2 Cache, 667 MHz FSB |
|
System Memory |
2 GB DDR2 667 MHz SODIMM (expandable) |
Onboard slot; max capacity varies by revision |
|
Buffered SRAM |
2 MB |
For fast data buffering (fieldbus/PLC tasks) |
|
Onboard Graphics |
Integrated, 128 MB Shared Memory |
Supports multi-screen visualization |
| Storage |
Main Storage |
160 GB SATA 3.5″ HDD (Default) |
No OS pre-installed; optional RAID 1 via controller |
|
Expansion Storage |
Front-access CompactFlash (CF) Slot |
No CF card included (optional boot drive) |
|
RAID Controller |
Onboard (Software/RAID 1 Support) |
For redundant storage configurations |
| Interfaces |
Ethernet |
2 x RJ45, 10/100/1000 Mbps (Gigabit) |
Dual ports for fieldbus/network redundancy |
|
USB |
4 x USB 2.0 (High Current) |
Supports power-hungry peripherals (e.g., scanners) |
|
Serial |
1 x COM1 (RS-232/RS-422/RS-485 via PROFIBUS/MPI) |
For PLC/fieldbus communication |
|
Expansion Slots |
2 x Free PCI Slots |
For motion control/DAQ cards (e.g., Siemens drive cards) |
|
Video |
Onboard (DVI-I / VGA via adapter) |
For HMI/SCADA display output |
| Watchdog & Monitoring |
Watchdog Timer |
Hardware/Software Monitoring |
Auto-recovery on system hang/fault |
|
Environmental Monitoring |
Temperature & Fan Speed Monitoring |
Triggers alerts/alarms for overheating/fan failure |
| Environmental Ratings |
Operating Temperature |
5 °C to 55 °C (41 °F to 131 °F) |
Ruggedized for industrial environments |
|
Storage Temperature |
-40 °C to 70 °C |
For transport/long-term storage |
|
Humidity |
10% to 90% (non-condensing) |
Resists moisture/corrosion |
|
Protection Class |
IP20 (Chassis) |
Meets industrial EMC/protection standards |
|
EMC Compliance |
EN 61000-6-2 / EN 61000-6-4 |
Industrial EMC immunity/emission |
|
Vibration/Shock |
IEC 60068-2-6 / IEC 60068-2-27 |
Withstands factory floor vibration/shock |
| Mechanical |
Dimensions |
305 mm × 279 mm × 76 mm (12.0″ × 11.0″ × 3.0″) |
Rack-mountable (19″ rack via optional kit) |
|
Weight |
~6.4 kg (14 lbs) |
Shipping weight includes accessories |
| Acoustics & Safety |
Acoustic Noise Level |
< 55 dB(A) |
Low noise for control room environments |
|
Safety Certifications |
IEC 60950, UL 60950 |
Industrial safety compliance |
|
NAMUR Compliance |
Power fail bridging (AC version) |
Meets NAMUR NE 44 for process automation |
