This is a Siemens SIMATIC IPC227D Nanobox PC (embedded industrial computer). Below are detailed electrical, hardware, and environmental parameters.
1. Power Supply & Electrical Parameters
| Parameter | Value |
|---|---|
| Supply Voltage | 24 V DC (nominal) |
| Voltage Range | 20.4 V DC – 28.8 V DC |
| Power Consumption (Typical) | ~15 W (Atom E660, 2 GB RAM, 80 GB SSD) |
| Input Current (Typical @ 24 V DC) | ~0.625 A |
| Input Current (Max) | ≤ 1.0 A |
| Power Fail Buffering | ≥ 20 ms |
| Isolation | Galvanic isolation between power supply and logic |
| Protection | Reverse polarity protection, overvoltage/overcurrent protection |
2. Hardware & Performance
Processor
- Type: Intel Atom E660
- Clock Speed: 1.3 GHz
- Cache: 512 KB L2 cache
- TDP: 3.5 W
Memory
- RAM: 2 GB DDR2 DRAM
- Non-Volatile Memory: 512 KB MRAM (NVRAM)
- Storage: 80 GB SATA SSD
- Expansion: 1x CompactFlash slot
Interfaces
- Ethernet: 2x 10/100/1000 Mbit/s RJ45 (Gigabit)
- Serial: 1x RS-232 (COM1)
- USB: 4x USB 2.0 (High Speed / High Current)
- Video: 1x DVI-D port
- Expansion: 1x PCIe x1 slot (internal)
3. Mechanical & Environmental
Dimensions & Mounting
- Form Factor: Nanobox PC (≈1 L volume)
- Mounting: DIN rail, wall, vertical, side mounting
- Enclosure: Closed metal, dust‑proof, IP20
Operating Conditions
- Temperature (Operating): 0 °C to +50 °C
- Temperature (Storage): -25 °C to +70 °C
- Humidity: 5% – 85% RH (non‑condensing)
- Vibration (Operating): 5–2000 Hz, 1 g (IEC 60068‑2‑6)
- Shock (Operating): 15 g, 11 ms (IEC 60068‑2‑27)
4. Software & Certifications
- OS: Windows Embedded Standard 7 SP1 (pre‑installed)
- Certifications: CE, FCC, UL, cUL, IEC 61000‑6‑2/‑6‑4
5. Key Notes
- This model is part of the IPC227D series with Atom E660, 2 GB RAM, 80 GB SSD, and no pre‑installed SIMATIC software.
- Power/current values are typical for standard configuration; actual draw may vary with peripherals.
