This is a rugged, rack-mountable industrial Box PC designed for 24/7 operation in harsh manufacturing environments. It features flexible power options, expandable slots, and comprehensive diagnostics. Below are the complete technical parameters, with a focus on electrical characteristics.
1. Power Supply & Electrical Parameters
表格
| Parameter | Value | Notes |
|---|---|---|
| AC Supply Voltage | 100–240 V AC | Wide-range, auto-ranging (-15%/+10%) |
| DC Supply Voltage | 24 V DC | Nominal, isolated (SELV) |
| DC Input Voltage Range | 19.2–28.8 V DC | -20%/+20% tolerance |
| AC Continuous Input Current | ≤ 1.7 A | At full load |
| AC Inrush Current | ≤ 50 A | Peak for 1 ms at startup |
| DC Continuous Input Current | ≤ 7.1 A | At full load |
| DC Inrush Current | ≤ 14 A | Peak for 30 ms at startup |
| Max Power Consumption | ≤ 176 W / 190 VA | At full load |
| Max 12 V Output Current | 12.5 A | Internal auxiliary supply |
| Power Supply Efficiency | Up to 88% | Typical at 50–70% load |
| Voltage Ride-Through (NAMUR) | Max 20 ms | At ≥ 0.85× nominal voltage |
| Isolation | SELV/PELV | Per IEC 61010-2-201 |
| Overvoltage Category | II | Per IEC 60664 |
| Pollution Degree | 2 | Per IEC 60664 |
2. Processor & Performance
表格
| Parameter | Value |
|---|---|
| CPU Options | Intel Core i3-4330TE (2C/4T, 2.4 GHz, 4 MB Cache)
Intel Xeon E3-1268L v3 (4C/8T, 2.3/3.3 GHz, 8 MB Cache) |
| TDP | 35 W (typical) |
| Memory (RAM) | 8 GB DDR3 1600 MHz (standard)
Max 16 GB (2× DIMM sockets) |
| Storage | 1× SATA 3.5″ HDD (250 GB) or 2.5″ SSD (240 GB)
1× Slimline SATA DVD±RW |
| Chipset | Intel C226 |
| Graphics | Intel HD Graphics P4600 (shared memory, up to 512 MB)
Dual displays: DVI-I + DisplayPort (max 3840×2160@60 Hz) |
3. Interfaces & Connectivity
表格
| Interface | Quantity | Specs |
|---|---|---|
| Ethernet | 2× RJ45 | 10/100/1000 Mbps (Gigabit), Intel WGI217LM/WGI210IT |
| USB | 5× USB 3.0 | 4× external (2× high-current), 1× internal for dongles |
| Serial | 1× COM1 | RS-232 (9-pin D-Sub) |
| Video | 1× DVI-I (DVI/VGA combo)
1× DisplayPort 1.4 |
Supports VGA via adapter |
| Expansion Slots | 1× PCI (185 mm)
1× PCIe x16 (185 mm) |
For fieldbus/motion/DAQ cards |
4. Mechanical & Environmental
表格
| Parameter | Value | |
|---|---|---|
| Dimensions (W×H×D) | 312 × 267 × 105 mm (standard) | |
| Weight | Approx. 7 kg | |
| Mounting | Rack-mount (19″), wall, or portrait (vertical) | |
| Protection Class | IP20 (standard)
IP65 (Panel Front version) |
|
| Operating Temperature | 5–55 °C (with expansions)
5–50 °C (with DVD drive) |
|
| Storage Temperature | -20–60 °C | |
| Relative Humidity | 5–95% (non-condensing) | |
| Vibration (Operating) | 0.075 mm (10–58 Hz)
9.8 m/s² (58–500 Hz) |
|
| Shock (Operating) | 50 m/s² (30 ms, half-sine) | |
| Noise Emission | < 55 dB(A) | Fan-cooled |
5. Software & Certifications
表格
| Item | Details |
|---|---|
| Supported OS | Windows 7/10 IoT Enterprise, Windows 10 Enterprise LTSB |
| Industrial Software | SIMATIC PCS 7, WinCC, WinAC, OPC UA, TIA Portal |
| Diagnostics | 4× dual-color LEDs (Power/RUN/Error/Maintenance)
DiagMonitor software (temp, HDD, watchdog, fan speed) |
| Certifications | CE, cULus, FCC Class A, EN 61000-6-2/6-4, RoHS |
| Reliability | MTBF > 100,000 hours |
