Product: SIMATIC IPC477E 15″ Touch Panel PC (Core i5-6442EQ, 8GB DDR4, 240GB SSD, 3× GbE, Fanless)
1. Electrical Parameters (Voltage, Current, Power)
| Parameter | Value |
|---|---|
| Supply Voltage (Rated) | 24 V DC |
| Permissible Voltage Range | 19.2 V DC – 28.8 V DC |
| Input Current (Max.) | ≤ 2.7 A @ 24 V DC |
| Power Consumption (Max.) | ≤ 65 W (24 V DC, full load) |
| Power Consumption (Typical) | ~50–55 W (24 V DC) |
| Power Consumption (Idle) | ~35–40 W |
| Inrush Current | ≤ 12 A (peak, short duration) |
| Voltage Dip Ride‑Through | ≥ 20 ms |
| Protection Class | III (SELV‑compliant power supply required) |
| Reverse Polarity Protection | Yes |
| Overvoltage / Overcurrent Protection | Integrated |
2. Display & Touch
| Parameter | Value |
|---|---|
| Display Type | 15″ TFT LCD |
| Resolution | 1280 × 800 (WXGA) |
| Touch Type | Analog resistive single‑touch |
| Brightness | 300 cd/m² |
| Contrast Ratio | 700:1 |
| Viewing Angle | Horizontal: ±80°, Vertical: ±70° |
| Response Time | 25 ms |
| Backlight Lifetime | ≥ 50,000 hours |
3. Core Hardware
| Parameter | Value |
|---|---|
| Processor | Intel Core i5‑6442EQ (4C/4T, 1.9 GHz base, 2.7 GHz turbo, 6 MB cache, Intel AMT 11.0) |
| Memory (RAM) | 8 GB DDR4‑2400 SO‑DIMM (non‑ECC; max. 16 GB) |
| Storage | 240 GB SATA SSD (non‑replaceable) |
| Graphics | Intel HD Graphics 530 (integrated) |
| BIOS | UEFI |
| Non‑Volatile Memory | 512 KB (battery‑independent retentive memory) |
| Operating System | Without OS (bare‑bone) |
4. Interfaces
| Interface | Quantity / Type |
|---|---|
| Ethernet | 3 × 10/100/1000 Mbps RJ45 (PROFINET / Industrial Ethernet) |
| USB | 1 × USB 2.0 (front, 500 mA); 4 × USB 3.0 (rear) |
| Video Output | 2 × DisplayPort (DP) |
| Serial | None (no RS‑232 / 422 / 485) |
| Expansion | No PCIe slot |
| Audio | None |
5. Environmental & Mechanical
| Parameter | Value |
|---|---|
| Operating Temperature | 0 °C to +45 °C |
| Storage / Transport Temperature | −20 °C to +60 °C |
| Relative Humidity | 5% – 85% (non‑condensing) |
| Ingress Protection | Front: IP65; Rear: IP20 |
| Vibration Resistance | IEC 60068‑2‑6 (operational: 5–2000 Hz, 1 g) |
| Shock Resistance | IEC 60068‑2‑27 (operational: 15 g, 11 ms) |
| Cooling | Fanless (passive convection) |
| Dimensions (W × H × D) | 415 mm × 310 mm × 76 mm |
| Mounting Cutout (W × H) | 396 mm × 291 mm |
| Weight | Approx. 7.1 kg |
| Mounting | Panel mount / VESA 75×75 / 100×100 |
