6SL3220-1YE38-0UF0
SINAMICS G120X Rated power: 45 kW At 110% 60s, 100% 240 s Unfiltered 380-480 V 3 AC +10/-20% 47-63 Hz Ambient temperature -20 to +45 °C Size: FSE Degree of protection IP20 / UL open type painting 3C2 without operator panel Without IO expansion Fieldbus integrated: PROFINET PN, Ethernet IP
| Product | |
| Article Number (Market Facing Number) | 6SL3220-1YE38-0UF0 |
| Product Description | SINAMICS G120X Rated power: 45 kW At 110% 60s, 100% 240 s Unfiltered 380-480 V 3 AC +10/-20% 47-63 Hz Ambient temperature -20 to +45 °C Size: FSE Degree of protection IP20 / UL open type painting 3C2 without operator panel Without IO expansion Fieldbus integrated: PROFINET PN, Ethernet IP |
| Product family | SINAMICS G120X |
| Power Module | |
| Power Rated | 45kW |
| Power voltage | 380-480 V 3 AC +10/-20% |
| Frequency | 47-63 Hz |
| AMBIENT TEMP | -20 to +45 °C |
| Fieldbus integrated | PROFINET PN, Ethernet IP |
| PROTECTION | IP20 |
| Warranty | 1 YEAR |
| Net Weight (kg) | 31.000 Kg |
| Packaging Dimension | 425.00 x 395.00 x 610.00 mm |
| Country of origin | Great Britain |
| Quantity Unit | 1 Piece |
