6SL3223-0DE31-1AG1
SINAMICS G120P Power Module PM230 with integrated Class A filter Degree of protection IP55/UL Type 12 380-480 V 3 AC +10/-10% 47-63 Hz Power low overload: 11kW at 150% 3s, 110% 57s, 100% 240 s; Ambient temperature -10 to +40 °C (LO) 620x 230x 249 (HxWxD), FSC without Control Unit and operating unit released for CU230P-2 Firmware version V4.3.2 or higher
| Product | |
| Article Number (Market Facing Number) | 6SL3223-0DE31-1AG1 |
| Product Description | SINAMICS G120P Power Module PM230 with integrated Class A filter Degree of protection IP55/UL Type 12 380-480 V 3 AC +10/-10% 47-63 Hz Power low overload: 11kW at 150% 3s, 110% 57s, 100% 240 s; Ambient temperature -10 to +40 °C (LO) 620x 230x 249 (HxWxD), FSC without Control Unit and operating unit released for CU230P-2 Firmware version V4.3.2 or higher |
| SINAMICS G120P | |
| Power Module PM230 | |
| Power voltage | 380-480 V 3 AC +10/-10% |
| Frequency | 47-63 Hz |
| OUTPUT LOW OVERLOAD | 11kW |
| AMBIENT TEMP | -10 to +40 °C |
| Size | 620x 230x 249 (HxWxD), FSC |
| Protection | IP55/UL |
| Net Weight (kg) | 9,500 Kg |
| Package size unit of measure | 0,259 x 0,686 x 0,296M |
| Country of origin | Great Britain |
| Quantity Unit | 1 Piece |
| Additional Product Information | |
| EAN | 4042948671658 |
| UPC | Not available |
| Commodity Code | 85044095 |
| LKZ_FDB/ CatalogID | D11.1SD |
| Product Group | 3576 |
| Group Code | R220 |
