6ES7660-6DE21-1AE0
SIMATIC PCS 7 Industrial Workstation IPC847D; (rack PC, 19″, 4 U), interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x display port; 1x COM, 2x PS/2, audio; 2x USB 3.0; 2x USB 2.0 on rear side, 1x USB 3.0; 1x USB 2.0, front-side; 1x USB 3.0 internal; temperature and fan monitoring; watchdog; card retainer; Core I5-4570TE (2C/4T, 2.7 GHz, 4 MB cache, TB, VT-D, AMT); ES/OS Single Station; 1x 1 TB HDD SATA in removable frame, on front; 16 GB DDR3 SDRAM (2x 8 GB), Dual Channel; Industrial Ethernet (CP1623); PCS 7 V8.1 SP1 pre-installed; Windows 7 Ultimate, 64 bit, MUI (en/de/fr/it/es/cn); Bus module 11 slots: 3x PCI, 3x PCIE X4, 5X PCIE X16, DVD +/-RW (slim); + multi monitor 2 screens VIA Onboard interfaces + 1x adapter cable (Display Port according to DVI-D); 100/240V industrial power supply unit with NAMUR; power supply cable Europe
| Product | |
| Article Number (Market Facing Number) | 6ES7660-6DE21-1AE0 |
| Product Description | SIMATIC PCS 7 Industrial Workstation IPC847D; (rack PC, 19″, 4 U), interfaces: 2x Gbit LAN (RJ45), 1x DVI-I, 2x display port; 1x COM, 2x PS/2, audio; 2x USB 3.0; 2x USB 2.0 on rear side, 1x USB 3.0; 1x USB 2.0, front-side; 1x USB 3.0 internal; temperature and fan monitoring; watchdog; card retainer; Core I5-4570TE (2C/4T, 2.7 GHz, 4 MB cache, TB, VT-D, AMT); ES/OS Single Station; 1x 1 TB HDD SATA in removable frame, on front; 16 GB DDR3 SDRAM (2x 8 GB), Dual Channel; Industrial Ethernet (CP1623); PCS 7 V8.1 SP1 pre-installed; Windows 7 Ultimate, 64 bit, MUI (en/de/fr/it/es/cn); Bus module 11 slots: 3x PCI, 3x PCIE X4, 5X PCIE X16, DVD +/-RW (slim); + multi monitor 2 screens VIA Onboard interfaces + 1x adapter cable (Display Port according to DVI-D); 100/240V industrial power supply unit with NAMUR; power supply cable Europe |
| Product family | SIMATIC PCS 7 |
| Industrial Workstation IPC847D | |
| rack PC | |
| Size | 19″ |
| Processor type/CPU | Core I5-4570TE |
| Memory capacity | 16 GB |
| Dual Channel | |
| Harddisk | 1 TB |
| Operating system/OS | Windows 7 Ultimate, 64 bit, MUI |
| Network Interface | 2x Gbit LAN (RJ45) |
| Other Interface | 1x DVI-I, 2x display port; 1x COM, 2x PS/2, audio; 2x USB 3.0; 2x USB 2.0 on rear side, 1x USB 3.0; 1x USB 2.0 |
| Power supply | 100/240V |
| Warranty | 1 year |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 84715000 |
| LKZ_FDB/ CatalogID | STPCS7 |
| Product Group | 4519 |
| Group Code | R1TP |
