6SL3210-1PC22-8UL0
SINAMICS POWER MODULE PM240-2 WITHOUT FILTER WITH BUILT IN BRAKING CHOPPER 3AC200-240V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 5,5KW FOR 200% 3S,150% 57S,100% 240S AMBIENT TEMP -10 TO +50 DEG C OUTPUT LOW OVERLOAD: 7,5KW FOR 150% 3S,110% 57S,100% 240S AMBIENT TEMP -10 TO +40 DEG C 355 X 140 X 165 (HXWXD), FSC PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED FOR CU FIRMWARE- VERSION V4.6
| Product | |
| Article Number (Market Facing Number) | 6SL3210-1PC22-8UL0 |
| Product Description | SINAMICS POWER MODULE PM240-2 WITHOUT FILTER WITH BUILT IN BRAKING CHOPPER 3AC200-240V +10/-10% 47-63HZ OUTPUT HIGH OVERLOAD: 5,5KW FOR 200% 3S,150% 57S,100% 240S AMBIENT TEMP -10 TO +50 DEG C OUTPUT LOW OVERLOAD: 7,5KW FOR 150% 3S,110% 57S,100% 240S AMBIENT TEMP -10 TO +40 DEG C 355 X 140 X 165 (HXWXD), FSC PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED FOR CU FIRMWARE- VERSION V4.6 |
| Product family | SINAMICS |
| POWER MODULE PM240-2 | |
| Input Power voltage | 3AC200-240V +10/-10% |
| Frequency | 47-63HZ |
| OUTPUT HIGH OVERLOAD | 5,5KW |
| AMBIENT TEMP | -10 TO +50 DEG C |
| OUTPUT LOW OVERLOAD | 7,5KW |
| AMBIENT TEMP | -10 TO +40 DEG C |
| Size | 355 X 140 X 165 (HXWXD), FSC |
| Protection | IP20 |
| Net Weight (kg) | 4,800 Kg |
| Package size unit of measure | 157,00 x 185,00 x 440,00MM |
| Country of origin | Great Britain |
| Quantity Unit | 1 Piece |
| Additional Product Information | |
| EAN | 4042948666296 |
| UPC | 887621831042 |
| Commodity Code | 85044087 |
| LKZ_FDB/ CatalogID | D11.1SD |
| Product Group | 9772 |
| Group Code | R220 |
