6SL3220-3YD42-0UB0
SINAMICS G120XA Rated power 75kW 3AC 380V -20% to 440V +10% unfiltered 110% 60s per 600s with integrated IOP-2 Integrated Fieldbus: MODBUS RTU, BACnet MS/TP, USS 6DI, 4DQ, 2AI, 2AQ, 1Mot_t Protection: IP20 Frame Size: FSF 709x305x360 (HxWxD)
| Specification | Details |
| Model Number | 6SL3220-3YD42-0UB0 |
| Product Series | SINAMICS G120XA |
| Rated Power | 75 kW |
| Supply Voltage | 3AC 380V (-20%) to 440V (+10%) |
| Filter | Unfiltered |
| Overload Capability | 110% for 60s per 600s |
| Operator Panel | Integrated IOP-2 |
| Integrated Fieldbus | MODBUS RTU, BACnet MS/TP, USS |
| Digital Inputs | 6 DI |
| Digital Outputs | 4 DQ |
| Analog Inputs | 2 AI |
| Analog Outputs | 2 AQ |
| Motor Temperature Sensor | 1 Mot_t |
| Protection Class | IP20 |
| Frame Size | FSF |
| Dimensions (HxWxD) | 709 x 305 x 360 mm |
| Net Weight | 66.8 kg |
| Country of Origin | China |
