6SL3220-3YD40-0UB0
SINAMICS G120XA Rated power 55kW 3AC 380V -20% to 440V +10% unfiltered 110% 60s per 600s with integrated IOP-2 Integrated Fieldbus: MODBUS RTU, BACnet MS/TP, USS 6DI, 4DQ, 2AI, 2AQ, 1Mot_t Protection: IP20 Frame Size: FSE 551x275x239 (HxWxD)
| Specification Category | Details |
| Product Name | SINAMICS G120XA Converter |
| Electrical Data | |
| Rated Power | 55 kW |
| Supply Voltage | 3AC 380V -20% to 440V +10% |
| Overload Capability | 110% for 60s per 600s |
| Physical & Protection | |
| Protection Class | IP20 |
| Frame Size | FSE |
| Dimensions (HxWxD) | 551 x 275 x 239 mm |
| Net Weight | 27.00 Kg |
| Control & Interfaces | |
| Operator Panel | Integrated IOP-2 |
| Integrated Fieldbus | MODBUS RTU, BACnet MS/TP, USS |
| Digital Inputs | 6 DI |
| Digital Outputs | 4 DQ |
| Analog Inputs | 2 AI |
| Analog Outputs | 2 AQ |
| Motor Temperature Sensor | 1 x Mot_t (e.g., PTC/KTY) |
| General Information | |
| Filter Type | Unfiltered |
| Country of Origin | China |
