6SL3210-1NE23-8AL0
SINAMICS G120 Power Module PM230 with integrated Class A filter Degree of protection IP20 380-480 V 3 AC +10/-10% 47-63 Hz Power low overload: 18.5kW at 150% 3s, 110% 57s, 100% 240 s; Ambient temperature 0 to +40 °C (LO) 355x 140x 165 (HxWxD), FSC without Control Unit and operating unit released for CU240B/E-2 and CU230P-2 Firmware version V4.4 or higher Note: PM230 supported no safety
| Product | |
| Article Number (Market Facing Number) | 6SL3210-1NE23-8AL0 |
| Product Description | SINAMICS G120 Power Module PM230 with integrated Class A filter Degree of protection IP20 380-480 V 3 AC +10/-10% 47-63 Hz Power low overload: 18.5kW at 150% 3s, 110% 57s, 100% 240 s; Ambient temperature 0 to +40 °C (LO) 355x 140x 165 (HxWxD), FSC without Control Unit and operating unit released for CU240B/E-2 and CU230P-2 Firmware version V4.4 or higher Note: PM230 supported no safety |
| Product family | SINAMICS G120 |
| Power Module PM230 | |
| Degree of protection | IP20 |
| Power voltage | 380-480 V 3 AC +10/-10% |
| Frequency | 47-63 Hz |
| Power low overload | 18.5kW |
| Ambient temperature | 0 to +40 °C (LO) |
| Size | 355x 140x 165 (HxWxD), FSC |
| Successor information | |
| Successor | 6SL3210-1NE23-8AG1 |
| Successor Description | SINAMICS G120 Power Module PM230 with integrated Class A filter Degree of protection IP20 380-480 V 3 AC +10/-10% 47-63 Hz Power low overload: 18.5kW at 150% 3s, 110% 57s, 100% 240 s; Ambient temperature 0 to +40 °C (LO) 355x 140x 165 (HxWxD), FSC without Control Unit and operating unit released for CU240B/E-2 and CU230P-2 Firmware version V4.4 or higher |
| Net Weight (kg) | 5,050 Kg |
| Package size unit of measure | 157,00 x 185,00 x 440,00MM |
| Country of origin | Great Britain |
| Quantity Unit | 1 Piece |
| Additional Product Information | |
| EAN | 4042948661482 |
| UPC | 887621218034 |
| Commodity Code | 85044088 |
| LKZ_FDB/ CatalogID | D11.1SD |
| Product Group | 9777 |
| Group Code | R220 |
