6AV7885-0AK28-3BA8
SIMATIC HMI IPC 577C PCI slot, 4 USB (back)+1 USB (front), Ethernet (10/100/1000), 12″ Touch display ; Core 2 Duo 1.86 GHz, PROFINET (IE); 2x 1 Gbit 2 GB -RAM, DDR3; 2nd mass storage: 320 GB HDD SATA 1st mass storage (Operating system optional): CF card: 4 GB Windows Embedded Standard 2009 pre-installed, (only possible with CF or SSD) without expansion (software) 24 V DC power supply
| Product | |
| Article Number (Market Facing Number) | 6AV7885-0AK28-3BA8 |
| Product Description | SIMATIC HMI IPC 577C PCI slot, 4 USB (back)+1 USB (front), Ethernet (10/100/1000), 12″ Touch display ; Core 2 Duo 1.86 GHz, PROFINET (IE); 2x 1 Gbit 2 GB -RAM, DDR3; 2nd mass storage: 320 GB HDD SATA 1st mass storage (Operating system optional): CF card: 4 GB Windows Embedded Standard 2009 pre-installed, (only possible with CF or SSD) without expansion (software) 24 V DC power supply |
| Product family | SIMATIC HMI |
| IPC 577C | |
| Size | 12″ Touch display |
| Processor type/CPU | Core 2 Duo |
| Network Interface | PROFINET (IE) |
| Other interface | 4 USB (back)+1 USB (front), Ethernet (10/100/1000) |
| Memory capacity | 2 GB |
| Harddisk | 320 GB |
| Operating system/OS | Windows Embedded Standard 2009 pre-installed |
| Power supply | 24 V DC |
| Programming software | without |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 84714100 |
| LKZ_FDB/ CatalogID | ST80E |
| Product Group | 4386 |
| Group Code | R144 |
