1794-OV16
Allen-Bradley
I/O Module, 16 Digital, Sink Output, 24VDC
| Technical specifications for 1794-OV16 | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital Sinking Output Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OV16 |
| UPC | 612598172795 |
| Weight | 0.38 lbs (0.17 kg) |
| Outputs | 16 Sinking |
| On-state Voltage nom. | 24V DC |
| Output Current Rating | 8.0A |
| Off-state Voltage max. | 31.2V DC |
| On-state Current max. | 500mA per Channel |
| Off-state Leakage | 0.5mA max. |
| On-state Voltage Drop max. | 0.2V DC max. |
| Flexbus Current | 80mA |
| Power Dissipation | 4.2W @ 31.2V DC max. |
| Thermal Dissipation | 14.3 BTU/hr. @ 31.2V DC max. |
