touch panel display, Harmony ST6, 7inch wide display, 1COM, 2Ethernet, USB host&device, 24V DC
| Main | |
| Range of Product | Harmony ST6 |
| Product or Component Type | Touch panel screen |
| Software package | EcoStruxure Operator Terminal Expert |
| Processor name | ARM Cortex-A8 |
| Processor frequency | 800 MHz |
| Memory description | 1 GB device memory |
| 128 MB user data memory | |
| 512 KB backup memory | |
| Complementary | |
| Display size | 7 inch |
| Display Type | Colour TFT LCD |
| Display colour | 16 million colours |
| Display Resolution | 800 x 480 pixels WVGA |
| Touch panel | Single touch analogue resistive |
| Backlight lifespan | 20000 hours white |
| Brightness | 16 levels |
| Character font | ASCII |
| ASCII (European characters) | |
| Chinese (simplified Chinese) | |
| Japanese (ANK, Kanji) | |
| Katakana | |
| Korean | |
| Taiwanese (traditional Chinese) | |
| [Us] rated supply voltage | 24 V DC +/- 20 %) |
| Power Consumption in W | 10.4 W |
| Inrush current | 30 A |
| Local signalling | Status LED green, steady offline |
| Status LED green, steady operating | |
| Status LED green, flashing operating | |
| Status LED green, faded stand-by | |
| Status LED orange, flashing software starting up | |
| Status LED red, steady power supply (ON) | |
| Status LED red, flashing operating | |
| Status LED red, off power supply (OFF) | |
| Number of pages | 200 application pages |
| Port Ethernet | 10/100BASE |
| Integrated connection type | 1 COM1 serial link – female RJ45 – RS232C/RS485 2400…115200 bps)bottom |
| 1 USB 2.0 type Aback | |
| 1 USB 2.0 type micro Bback | |
| 2 Ethernet – female RJ45bottom | |
| Supply | External supply |
| Realtime clock | Built-in 0…50 °C |
| Built-in 10…90 % RH | |
| Downloadable protocols | Modbus |
| Uni-TE | |
| Third party protocols | |
| Product brand | Schneider Electric Modicon |
| Mitsubishi Melsec | |
| Omron Sysmac | |
| Rockwell Automation Allen-Bradley | |
| Siemens Simatic | |
| Fixing mode | Ø 22 mm hole 1.5 to 6 mm thick panel UL 61010-2-201 |
| Ø 22 mm hole IEC 61131-2 | |
| Ø 22 mm hole IEC 61000-6-2 | |
| Enclosure Material | PC |
| Front material | Plastic |
| Marking | CE |
| Cut-out dimensions | Ø 22.5 mm |
| Height | 5.4 in (137.2 mm) |
| Width | 7.9 in (201.2 mm) |
| Depth | 2.3 in (57.7 mm) |
| Net Weight | 1.68 lb(US) (0.76 kg) |
| Environment | |
| Immunity to microbreaks | 2 ms |
| Standards | IEC 61000-6-4 |
| IEC 61000-6-2 | |
| IEC 61131-2 | |
| UL 61010-2-201 | |
| CSA C22.2 No 61010-2-201 | |
| CSA C22.2 No 213 | |
| Product Certifications | CE |
| UKCA | |
| cULus | |
| RCM | |
| KC | |
| cULus Class 1 Division 2 | |
| DNV | |
| ABS | |
| RINA | |
| BV | |
| Directives | 2014/35/EU – low voltage directive |
| 2014/30/EU – electromagnetic compatibility | |
| Ambient Air Temperature for Operation | 32…122 °F (0…50 °C) |
| Ambient Air Temperature for Storage | -4…140 °F (-20…60 °C) |
| Relative humidity | 10…90 % non-condensing |
| Operating altitude | 6561.68 ft (2000 m) |
| IP degree of protection | IP20 IEC 61131-2 rear panel) |
| IP65 IEC 61131-2 front panel) | |
| NEMA degree of protection | NEMA 4 front panel (indoor use) |
| NEMA 13 front panel (in enclosure) | |
| Shock resistance | 147 m/s² 11 ms X, Y, Z directions for 10 cycles (approx. 100 min))IEC 61131-2 |
| Vibration resistance | +/- 3.5 mm 5…9 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) IEC 61131-2 |
| 9.8 m/s² 9…150 Hz) | |
| Electromagnetic compatibility | Electrical fast transient/burst immunity test – test level: 2 kV (power ports) conforming to IEC 61000-4-4 |
| Electrical fast transient/burst immunity test – test level: 1 kV (signal ports) | |
| Electrostatic discharge immunity test – test level: 6 kV (contact discharge) conforming to IEC 61000-4-2 level 3 | |
| Electrostatic discharge immunity test – test level: 8 kV (air discharge) | |
| Ordering and shipping details | |
| Category | US10MC222565 |
| Discount Schedule | 0MC2 |
| GTIN | 3606481856418 |
| Returnability | Yes |
| Country of origin | SG |
