20F1AGD125AN0NNNNN — PowerFlex Air Cooled 753 AC Drive
ALLEN-BRADLEY PowerFlex Air Cooled 753 AC Drive
| Technical specifications for 20F1AGD125AN0NNNNN | |
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AGD125AN0NNNNN |
| Weight | 32.00 lbs (14.51 kg) |
| Input Type | AC Input with Precharge and no DC Terminals |
| Enclosure Type | IP54 class, NEMA/UL Type 12 Enclosure |
| Frame Size | 6 |
| Voltage Rating | 480 Volts AC / 650 Volts DC |
| Output Current (Normal Duty) | 125 Amps |
| Power (Normal Duty) | 100 Horsepower (HP) |
| Filtering and CM Cap Configuration | Filtered with common mode capacitor jumper removed |
| Dynamic Braking Option | No Internal Transistor, and No Internal Resistor Included |
| Operator Interface | Blank / No HIM provided |
| Efficiency | 97.5% at rated amps, nominal line volts |
| Operating Temperature | 0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit) |
| Relative Humidity | 5 to 95% non-condensing |
| Storage Temperature | -40 to +70 degrees Celsius (-40 to +158 degrees Fahrenheit) |
