20G1AND302JA0NNNNN
PowerFlex Air Cooled 755 AC Drive
PowerFlex 755 AC Drive, with Embedded Ethernet/IP, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Open Type, 302 Amps, 250HP ND, 200HP HD, 480 VAC, 3 PH, Frame 7, Filtered, CM jumper installed (preferred), DB Transistor, Blank (No HIM)
| Brand | Allen-Bradley |
| Manufacturer: | Rockwell Automation / Allen-Bradley |
| Product Family: | PowerFlex 753 |
| Input Voltage Class: | 480VAC |
| Nominal Motor Voltage | 460VAC |
| Input Phase: | 3-Phase |
| Output Current: | 302A |
| Output Power: | 250HP ND and 200HP HD |
| Operation with single phase with derate | Supported |
| Frame: | 7 |
| Enclosure Rating: | IP00 / IP20 |
| HIM: | No door mounted HIM |
| Dynamic Braking | Transistor |
| Part Number/Catalog No. | 20G1AND302JA0NNNNN |
| Series | PowerFlex 755 |
| Frames | 6…8 |
| Enclosure Type | AC Input with Precharge, no DC Terminals |
| Frames 2 | 2…7 |
| Enclosure Type 2 | IP20/IP00, NEMA/UL Type Open |
| Voltage | 480 Volts AC/650 Volts DC |
| Filtering | Yes |
| Default CM Cap Connection | Jumper Installed |
| Internal Resistor | No |
| Internal Transistor | Yes |
