1734-IB8SK
Digital Safety Input Module
POINT Guard IO Conformal Coated
| Technical specifications for 1734-IB8SK | |
| Manufacturer | Allen Bradley |
| Product Type | Digital Safety Input Module |
| Product Line | Point I/O 1734 |
| Part Number | 1734-IB8SK |
| UPC | 191326446617 |
| Weight | 0.56 lbs (0.26 kg) |
| Series | POINT Guard I/O |
| Number of Inputs | 8 |
| Product Description | Safety Input module with conformal coating |
| Conformal Coating | Yes |
| Module Type | Discrete safety input module |
| No. of Inputs | Eight (8); Sinking input |
| Input Voltage range | 18-30 VDC |
| Minimum On-state current | 3.3 mA |
| Terminal Base Type | 8-Point Terminal Base |
| Maximum Off-state current | 1.3 mA |
| Input reaction time | < 16.2 ms |
| Pulse Test Output | Four (4) |
| Output wiring | Current sourcing |
| Pulse Test Output current, per channel | 0.7 A, max |
| Pulse Test Output current, per module | 2.8 A @ 40 Deg. C. (per module) |
| Compatible controllers | GuardLogix, Compact GuardLogix, Smart Guard |
| Safety level compliance | SIL 3 / 4; Cat. 3 and 4 |
